IMB5 / IM3001 Class F / B Three Phase Asynchronous Electric Motor 0.25KW - 7.5KW

Ambient

Temperature range:

-15~40℃

Ambient humidity:

90%less than relative humidity

Altitude:

less than 1000m above sea level

Ambient condition:

no causticity gas, no dust, no heavy mental pollution, no flame, no salt crystallization

Supply power:

Voltage variable

±5%

frequency variable

±2%? Combine voltage and frequency variable : ±5%

Standard Feature:

Standard

IEC

Efficiency Level

IE2

Phase

Three-phase

Frame Size

H71~132 Aluminum Frame

Protect Feature

Totally Enclosed

Output Range

0.25~7.5KW

Voltage

380V

Frequency

50HZ

Pole

2,4,6

Protection Class

IP55

Insulation

F/B

Mounting

IMB5 /IM3001

Cooling

IC411

Duty

S1

Connection

” Y\" type for 3kW and downwards, \"D\" type for 4kW and upwards

Thermometry

Optional

Overload Times

According to IEC60034, the motors can withstand 1.5times rated voltage and rated current for 2 minutes.

Certification

CCC, CE,ISO9001

Special motors can be designed according to customers\' requirements

Motor??? Type

2 pole /3000 rpm

4 pole /1500 rpm

6pole /1000 rpm

kW

HP

kW

HP

kW

HP

YE2A-71M1

0.37

4.9

0.25

0.33

YE2A-80M1

0.75

1

YE2A-80M2

1.1

1.5

0.75

1

YE2A-90S

1.5

2

1.1

1.5

0.75

1

YE2A-90L

2.2

3

1.5

2

1.1

1.5

YE2A-100L

3.0

4

2.2

3

1.5

2

3

4

YE2A-112M

4.0

5.5

4

5.5

2.2

3

YE2A-132S

5.5

7.5
