Totally Enclosed IMB35 / IMV1 IC411 Industrial Electric Motors 10HP / 15HP / 20HP

FOB Price

Negotiable / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HD		Place of Origin	China
Model Number	YE2-2 pole

Product Description

Delivery Time:15 working days after order
Certification:CE/CCC/ISO9001

Description:

YE2-2 pole series high-efficiency three phase asynchronous motor is a development based on the YP2-2 pole series motor while considering the demand for energy conservation around the world. The mounting, bearings, terminal box, mounting dimensions are as the same as YP2 series. But its average efficiency is 2.55%higher than YP2 series motor.

According to IEC standard and Chinese energy-efficiency standard profoundly,this series reach the internationally general protection level(IP55)and insulation class (F insulation and B temperature rise).Boast several features such as high efficiency, high starting torque, low noise, more reliable structure and well appearance.

Adopt the cooling method of IC411 that is matured in the cooling and heat dissipation.

Our company has passed ISO9001 certification and followed its requirements from ordering, development, fabrication, inspection to sales service strictly.

Ambient
Temperature range:	-15~40℃
Ambient humidity:	90%less than relative humidity
Altitude:	less than 1000m above sea level
Ambient condition:	no causticity gas, no dust, no heavy mental pollution, no flame, no salt crystallization
Supply power:
Voltage variable	±5%
frequency variable	±2%? Combine voltage and frequency variable : ±5%
Standard Feature:
Standard	IEC/GB
Efficiency Level	IE2
Phase	Three-phase
Frame Size	H80~355 Cast iron frame
Protect Feature	Totally Enclosed
Output Range	0.75~375KW
Voltage	380V
Frequency	50HZ
Pole	2
Protection Class	IP55
Insulation	F/B
Mounting	IMB3 /IMB35/IMV1 or on your request
Cooling	IC411
Duty	S1
Connection	” Y\" type for 3kW and downwards, \"D\" type for 4kW and upwards
Thermometry	Optional
Certification	CCC, CE,ISO9001
Special motors can be designed according to customers\' requirements

Technical Specification (2 pole/3000r/min? 380V/50HZ)

Motor??? Type	Rated??? Power	Current	Rated?????? Speed	Rated?????? Torque	Power? Factor	Efficiency	Locked Current	Locked Torque	Maximum Torque	Weight
Rated Current	Rated Torque	Rated Torque
KW	HP	380V? InA	400V IoA	r/min	N.m	cosΦ	η%	Ist/IN	Tst/TN	TM/TN	kg
YE2-80M1-2	0.75	1	1.8	1.7	2845	2.4	0.82	77.
