Home Network 24 Port Cat5e Patch Panel 19" STP 150 Volts ISO CE

Home Network 24 Port Cat5e Patch Panel 19\" STP 150 Volts ISO CE

Quick Detail:

1.Type:Category 5e?24 ports STP

2.Color:black ? ? ? ? ? ? ?

3.Standard:ISO/IEC 11801 ,ANSI/TIA/EIA-568-B

4.gender:female

5.test:Fluck 4300 1800

6.Certificate:ISO 9001:2008

7.application:network

Description:

1. Design to mount to any standard 19\" patch panel

2. Space saving, high-density 1U (24 port)?
3.?IDC contract material: phosphor bronze with tin plating over nickel

4.110& krone punch down tools are available.

5. Sturdy Aluminum Plate around RH 5 Jacks

6. Phosphor bronze with 50 micro inches gold plated

7. Availabe with T568 A, T568B wiring pattern and meeting the requirement of cat6 standard

8. Color Coded TIA/EIA 568 A (international) and 568B (AT&T Standard) Wiring for Easy Installation

9. Termination accepts 22, 24, 26 AWG (0.64, 0.5 and 0.4) solid wires

10.? Metal sheet: Corrosion resistant steel sheet.

11. Plastic: fire self extinguish high impact plastic.

Electrical:

Angle:90,180 Degree

Current rating: 1.5 Amp Max.

Voltage rating: 150 Volts

Contact resistance: 20 m-ohm

Insulation Resistance: 500M-ohm

Dielectric Withstand Voltage: 1000 V AC RMS, 60Hz 1min

Materials:

Housing: PC UL94V-0

Termination: 110 Type?

IDC: PC UL94V-0, Accept 22-26 AWG Solid Wire.

PCB: FR4 1.6mm(0.04\") thickness, 2 layers

Contact: PC UL94V-0, 0.45mm(0.018\") Diameter Phosphor bronze with 3 u\" Gold plating on contact area.

Applications:

Patch management subsystem is the most important component is to achieve vertical lines and two horizontal cabling subsystem cross-connect hub.?

for Structure Cabling System

Competitive Advantage:

As a?factory,We supply goods: with stable quality ?good prices? shorter delivery time ??less minimum order quantity.

We are running?in?networking?business for nearly?10years,so our product of cabling are very rich,most? of?cabling accessories are available?with us.

All our goods are sell abroad, and we ?support our?customers with good service?? of?rich experience,which will save?much time&work.?
