petroleum / oil drill pump for Power switch pump Diameter 28-95mm
- T/T L/C D/P D/A
- 7 days
You May Like
-
Horizontal Oil well pumps of power-switched structure Max.O.D.88.9-121mm
-
professional oil well pumps for Case Study , thick oil Hydraulic feedback pump
-
high performance alloy steel drill pipe sub 2 3/8\"-6 5/8\" can be customized
-
well control equipment FC valve Full-bore design 2000PSI20000PSI
-
professional well control equipment for Union 2000PSI-20000PSI 1\"4
-
Oilfield equipment PFF gate valve well control equipment , 2000PSI-20000PSI
Product Details
| Brand Name | KOMAL | Place of Origin | China | |
| Model Number | 88.9-121 |
Product Description
Certification:API
petroleum pump Oil well pump for Power switch pump Diameter 28-95mm
Quick Detail:
1, Normal Diameter:28-95mm
2, plunger pump
3, oil well pump
4, Pump Constant:0.916-10.216
5, Max.O.D.88.9-121?m3/d
6, Length series of the plunger:0.6-1.5m?
Description:
The traveling valve of the pump is connected with the rod string through the draw rod. It forces the valve ball to switch depending on the mechanical force effect, thereby solves a series of problems including unreliable sealing with the valve seat when the valve ball switches untimely and the ball resisting the flowing of thick oil in the valve bonnet during the pumping process. It has strong thick oil pumping capability. The vapor lock of the thermal recovery and oil production has been well solved and the volumetric efficiency of the pump has been greatly improved. The pump can also be used in wells with larger oil gas content.
Applications:
Oil well,oil field,
Specifications :
|
Nominal diameter mm |
Length series of the plunger m |
Extension nipple length m |
Stroke range of the plunger m |
O.D. of the connecting oil pipe mm |
Diameter of the connecting pumping rod mm |
Pump constant m3/d |
Max. O.D. mm |
| 28 |
0.6 0.9 1.2 1.5 |
0.3 0.6 0.9 |
0.6-6.0 | 60.3,73.0 | 16 | 0.916 | 88.9 |
| 32 | 60.3,73.0 | 16 | 1.140 | 88.9 | |||
| 38 | 60.3,73.0 | 16/19 | 1.642 | 88.9 | |||
| 44 | 60.3,73.0 | 19 | 2.235 | 88.9 | |||
| 57 | 73.0 | 19 | 3.694 | 88.9 | |||
| 70 | 88.9 | 22 | 5.518 | 107 | |||
| 83 | 101.6 | 22 | 7.707 | 114 | |||
| 95 | 114.3 | 25 | 10.261 | 121 |
Competitive advantages:
Competitive price with top quality,professional export service,provide all products as customer’s requirement,respond within shortest time
