Product Details
| Brand Name | KOMAL | Place of Origin | China | |
| Model Number | 88.9-121mm |
Product Description
Certification:API
Oil weel pump for Double-seal Rod Pumps 0.6-1.5m
Quick Detail:
1, Normal Diameter:28-95mm
2, plunger pump
3, oil well pump
4, Pump Constant:0.916-10.216
5, Max.O.D.88.9-121?m3/d
6, Length series of the plunger:0.6-1.5m?
Description:
This pump adopts the top soft double seal or metal interference with seal, limit type forced locking structure
Sealing is reliable, stable operation; carry on limit pole unlock, locking and reliable; heavy oil wells, can be applied to heat production wells, fouling paraffin wells
Applications:
Oil well,oil field,
Specifications :
|
Nominal diameter mm |
Length series of the plunger m |
Extension nipple length m |
Stroke range of the plunger m |
O.D. of the connecting oil pipe mm |
Diameter of the connecting pumping rod mm |
Pump constant m3/d |
Max. O.D. mm |
| 28 |
0.6 0.9 1.2 1.5 |
0.3 0.6 0.9 |
0.6-6.0 | 60.3,73.0 | 16 | 0.916 | 88.9 |
| 32 | 60.3,73.0 | 16 | 1.140 | 88.9 | |||
| 38 | 60.3,73.0 | 16/19 | 1.642 | 88.9 | |||
| 44 | 60.3,73.0 | 19 | 2.235 | 88.9 | |||
| 57 | 73.0 | 19 | 3.694 | 88.9 | |||
| 70 | 88.9 | 22 | 5.518 | 107 | |||
| 83 | 101.6 | 22 | 7.707 | 114 | |||
| 95 | 114.3 | 25 | 10.261 | 121 |
Competitive advantages:
Competitive price with top quality,professional export service,provide all products as customer’s requirement,respond within shortest time
