Dental 160000RPM Air Bearing Spindle CNC Router Spindle ABLH516D / WWD1722

Compatible ABLH516D or WWD1722 160,000RPM KL161D Air Bearing Spindle PCB PRECISION DRILLING?

Quick Detail:

PRODUCT DESCRIPTION

KL161D high speed rotation and high accuracy spindle replace for ABL H516D or WW D1722 Full Range from 20,000 to 160,000 rpm, air bearing type in long life, spindle weight? 4.1kg with COLLET size 1/8” and body size ? 61.9. And FREQUENCY (HZ) is from 334-2760, SENSOR or Without For Choose.

Max power:0.85KW

Coolant:Water oil

Fixed voltage:200V

Fixed current:4A

Static Runout:<2μm

Dynamic Runout:<7μm

Vibration:1.0MM/S

Competitive Advantage:

Low Static

Low Dynamic RUN OUT

Stable character and long life

Power and very low heat generation

ATC feeder / ATC tool change for micromachining

KLKJ Advantage

The ?higher spindle speeds available allow for increased productivity whilst ensuring that accuracy and repeatability is maintained.

Advanced analysis and detailed design has created a spindle with exceptional reliability and increased efficiency.

KLKJ strong team available allows increased productivity and efficiency.?

APPLICATION :

PRINT CIRCUIT BOARD PRECISION DRILLING

HOLE RANGE: ?6.35mm-0.05mm

MACHINE REFERENCE:KLINGINBERG PLURITEC ；HITACHI ；LENZ ；ANDERSON ….

SPECIFICATION:

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?KL161 SPINDLE OUTLINE DRAWING

Why choose KLKJ?

With nearly 15 years technology in spindle maintenance, 10 years success experience for spindles parts production, and 9 years spindle R&D, KLKJ succeed in offer air bearing spindle up to 200krpm.

All spindles at the KLKJ are fully checked and tested using stringent quality control procedures. KLKJ ensures every repaired spindle passes the following points to make it in long life and stable character:

1.???? Air flow

2.???? Water flow

3.???? End float/lift off

4.???? Axial load (inner)

5.???? Axial load (outer)

6.???? Torque

? ? ? ? 7.? Static RUNOUT

? ? ? ? 8.? D
