Product Details
| Brand Name | Xinhai | Place of Origin | China | |
Product Description
Peripheral Transmission Slurry Gravity Thickener With Flexible Automatic Control System
Peripheral Transmission Thickener Slurry Thickener
Quick Detail:
1. Good flocculation of solid particles
2. Flexible automatic control system
3. Long operating life
Description:
Peripheral rotation, simple structure, low materials consumption
Applications:
The machine is suitable for dealing with large capacity and light density products. Mainly used for condensing concentrate and dewatering the tailings. It can be also used for condensing and cleaning the pulp with solid particles in coal, chemical, building materials and sewage treatment system.
Principle:
This thickener consists of round thickener and harrow scraping machine, the solid particles suspend in thickener settling by gravity, the pulp in the upper turn into clean water, so that the separation can be realized. Slime that sediment in the bottom of the thickener is discharged by the harrow scrapping continuously, and clean overflow from the upside.
Specifications :
| Model | Thickening Tank Diameter (mm) |
Thickening Tank Center Depth (mm) |
Capacity (t/d) |
Sedimentation Area (m2) |
Motor Model | Motor Power (kw) |
Weight (t) |
Note |
| NG-15 | 15000 | 3500 | 87～390 | 177 | Y132(M2)-6 | 5.5 | 9120 | Manual Lifting Rake |
| NG-18 | 18000 | 3500 | 560 | 255 | 1000 | |||
| NG-24 | 24000 | 3400 | 1000 | 452 | Y160M-6 | 7.5 | 24000 | |
| NG-30 | 30000 | 3940 | 1560 | 707 | 26420 | |||
| NG-45 | 45000 | 5060 | 2400 | 1590 | Y160L-6 | 11 | 50640 | |
| NG-53 | 53000 | 5070 | 3000 | 2202 | 60910 |
