Automatic Elevating Apparatus High Weir Spiral Classifier Machine Energy Saving
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Professional Mine Cyclone Assembly Hydrocyclone Separator Computer Selection
-
Normal Mineral separation agitated tanks For Agitating Pulp / Dewatering / Desliming
-
Large Capacity BF Flotation Cells for Separating Non - ferrous Metal , Flotation Machine
-
Convenient Adjustment Gravity Separator Machine Concentrating Table For Fine Minerals
-
Corrosion Resistant Magnetic Separator Machine Electromagnetic Iron Remover
-
Automatic Deep Cone Round Slurry Thickener , Low Power Consumption
Product Details
| Brand Name | Xinhai | Place of Origin | China | |
Product Description
Automatic Elevating Apparatus High Weir Spiral Classifier Machine Energy Saving
Energy Saving Automatic Elevating Apparatus High Weir Spiral Classifier
Quick Detail:
1. High efficient and energy saving
2. Long working life
3. The lining is made of Xinhai abrasion-resistant rubber
Description:
1 An automatic elevating apparatus is added to the discharge opening. The scoop in ball mill is eliminated.
2 The energy conservation is 1-1.5KW/ton
3 Since the scoop is dismantled, the trouble of high maintenance of scoop is completely saved.
4 The imbalanced impact on big and small gearings is greatly diminished.
Applications:
The high wire spiral classifier is applied in the classification of ore with particle size 0.83-0.15mm
Principle:
Fine ore pulps are fed into water tank through feeding opening located in the center of settling zone. Beneath the inclined water tank is the ore pulp classification zone where ore pulps are stirred by low-speeded impellers. Fine ore particles are lifted up and then spilled out the overflow opening; coarse ore particles precipitate down to tank bottom and are discharged via discharge opening.
Specifications :
| Type | Spec. |
Spiral rotation speed(r.p.m) |
Sand return capacity(t/d) |
Overflow capacity(t/d) |
Diameter of spiral(mm) |
Length of flume (mm) | Inclination of flume | Model of drive motor | Power of drive motor(kw) | Model of lifting motor | Power of lifting power(kw) | Weight(kg) |
| High weir type single spiral | FLG-300 | 7.7 | 30-80 | 10-30 | 300 | 3900 | 14-18 | Y100L1-4 | 2.2 | Manual | — | 668 |
| FLG-500 | 8 | 145-260 | 21-75 | 500 | 4390 | 14-18 | Y112M-6 | 2.2 | — | 1600 | ||
| FLG-750 | 7.8 | 255-564 | 65-154 | 750 | 5500 | 14-18 | Y132S-6 | 3 | — | 2716 | ||
| FLG-1000 | 6.7 | 473-1026 | 85 | 1000 | 6500 | 14-18 | Y132M2-6 | 5.5 | — | 4100 | ||
| FLG-1200 | 5,6,7 | 1165-1630 | 150 | 1200 | 6500 | 14-18 | Y132M2-6 | 5.5 | Y90L-4 | 1.5 | 8000 | |
| FLG-1500 | 2.5,4,6 | 1140-2730 | 235 | 1500 | 8265 | 14-18 | Y160M-6 | 7.5 | Y100L1-4 | 2.2 | 11827 | |
| FLG-2000 | 3.6,5.5 | 3240-5940 | 400 | 2000 | 8400/9900 | 14-18 | Y160L-6/4 | 11；15 | Y100L2-4 | 3 | 20814 | |
| FLG-2400 | 3.64 | 6800 | 580 | 2400 | 9130 | 14-18 | Y200L2-6 | 20 | Y100L2-4 | 3 | 25650 | |
| FLG-3000 | 3.2 | 11625 | 890 | 3000 | 14300 | 14-18 | Y200L-6 | 30 | Y112M-4 | 4 | 34480 | |
| High weir type double spirals | 2FLG-1200 | 5,6,7 | 2340-3200 | 310 | 1200 | 6500 | 14-18 | Y132M2-6 | 5.5×2 | Y100L1-4 | 2.2×2 | 15840 |
| 2FLG-1500 | 2.5,4,6 | 2240-5360 | 460 | 1500 | 8230 | 14-18 | Y160M-6 | 7.5×2 | Y100L1-4 | 2.2×2 | 22110 | |
| 2FLG-2000 | 3.6,5.5 | 7780-11880 | 800 | 2000 | 8400 | 14-18 | Y160L-4 | 2×15 | Y100L2-4 | 3.0×2 | 34621 | |
| Y200L2-6 | 22 |
