Wearable Rubber Liner Submerged Spiral Classifier For Mining High Efficient
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Industry Hydraulic Sand Separator Hydrocyclone Equipment for Ore Processing
-
High Productive Efficiency Agitation Tank For Chemical Reagent , Mixing Tank With Agitator
-
Powerful Energy Saving Steel Ores Agitation Tank With Powerful Stirring Capability
-
High Efficient Large Pulp Circulation Wemco Flotation Cells , Low Rotary Speed
-
Simple Structure Air Spreading Inflation Flotation Cell , Flotation Equipment
-
Low Power Consumption SF Flotation Cell / Separator , Ore Beneficiation Plant
Product Details
| Brand Name | Xinhai | Place of Origin | China | |
Product Description
Wearable Rubber Liner Submerged Spiral Classifier For Mining High Efficient
Fine Classification Wearable Rubber Liner Submerged Spiral Classifier
Quick Detail:
1. High efficient and energy saving
2. Long working life
3. The lining is made of Xinhai abrasion-resistant rubber
4. The area and depth of settling zone are huge
Description:
1. The spiral of overflow end is completely immersed below liquid level of settling area. The settling zone has huge area and depth.
2. The energy conservation is 1-1.5KW/ton
3. Since the scoop is dismantled, the trouble of high maintenance of scoop is completely saved.
4. The imbalanced impact on big and small gearings is greatly diminished.
Applications:
Applicable to fine classification
Principle:
Fine ore pulps are fed into water tank through feeding opening located in the center of settling zone. Beneath the inclined water tank is the ore pulp classification zone where ore pulps are stirred by low-speeded impellers. Fine ore particles are lifted up and then spilled out the overflow opening; coarse ore particles precipitate down to tank bottom and are discharged via discharge opening.
Specifications :
| Type | Spec. | Spiral Rotation Speed(r.p.m) | Sand Return Capacity(t/d) | Overflow Capacity(t/d) | Diameter of Spiral(mm) | Length of Flume(mm) | Inclination of Flume | Model of Drive Motor | Power of Drive Motor(kw) | Model of Lifting Motor | Power of Lifting Motor(kw) | Weight(kg) |
| Submerged Single Spiral | FLC-1000 | 2.5,3.5,5,7.4 | 160-700 | 85 | 1000 | 6500 | 14-18 | Y132M2-6 | 5.5 | Manual | — | 5195 |
| FLC-1200 | 5,6,7 | 1150-1640 | 120 | 1200 | 8400 | 14-18 | Y160M-6 | 7.5 | Y90L-4 | 1.5 | 9583 | |
| FLC-1500 | 2.5,4,6 | 1140-2740 | 185 | 1500 | 10500 | 14-18 | Y160L-6 | 7.5 | Y100L1-4 | 2.2 | 14226 | |
| FLC-2000 | 3.6,5.5 | 3890-5940 | 400 | 2000 | 13000 | 14-18 | Y160M-6 | 11 | Y100L2-4 | 3 | 27753 | |
| Y160L-4 | 15 | |||||||||||
| FLC-2400 | 3.64 | 6800 | 455 | 2400 | 14130 | 14-18 | Y200L1-6 | 18.5 | Y112M-4 | 4 | 32467 | |
| FLC-3000 | 3.2 | 11650 | 705 | 3000 | 14300 | 14-18 | Y200L-4 | 30 | Y112M-4 | 4 | 43500 | |
| Submerged Double Spiral | 2FLC-1200 | 3.8,6 | 1770-2800 | 240 | 1200 | 8400 | 14-18 | Y160M-6 | 7.5×2 | Y100L1-4 | 2.2×2 | 19610 |
| 2FLC-1500 | 2.5,4,6 | 2240-5360 | 370 | 1500 | 10500 | 14-18 | Y160M-6 | 7.5×2 | Y100L1-4 | 2.2×2 | 27450 | |
| 2FLC-2000 | 3.6,5.5 | 7780-11880 | 640 | 2000 | 12900 | 14-18 | Y160L-6/4 | 2×11,2×15 | Y100L2-4 | 3.0×2 | 50621 | |
| Y200L2-6 | 22 | |||||||||||
| Y200L-4 | 30 | |||||||||||
| 2FLC-2400 | 3.67 | 13700 | 910 | 2400 | 14130 | 14-18 | Y225S-4 | 37 | Y112M-4 | 4.0×2 | 65283 | |
| 2FLC-3000 | 3.2 | 23300 | 1410 | 3000 | 14300 | 14-18 | Y225M-4 | 45 | Y112M-4 | 4.0×2 | 84900 |
