CNC Stepper Motor Kit 3 Axis 200W with 1.8 degree 56 OZ-IN
- T/T L/C D/P D/A
- 7 days
You May Like
-
4 Leads Stepper Motor Kit 3 Axis Nema 17 4000g.cm 12 Volt - 36 Volt
-
57mm dc Electric brushless motor BLDC with 3 Phase 36 Volt JK57BLS
-
8 Pole Electric brushless dc motor Delta wtih high torque , 24000RPM
-
24V / 48V electric brushless dc motor 10000rpm 40 Watt , High speed for CNC
-
Electric Brushless DC Motor 6 Lead 22mm with 24 Volt and three Phase
-
Electronic 5 phase stepper motor 110mm 12 N.m- 25 N.m for printer 110BYGH
Product Details
Brand Name | JK | Place of Origin | China | |
Product Description
Certification:CE,ROHS ,ISO9001
CNC Stepper Motor Kit 3 Axis 200W with 1.8 degree 56 OZ-IN
Part No.:? JK42HS40-1704 Frame Size:? NEMA17 Step Angle: 1.8 degree Voltage:? 3.4V Current:?? 1.7 A/phase Resistance: 2.0 Ohm/phase Inductance: 3.0 mH/phase Holding torque:? 4000g-cm? 56OZ-IN Rotor inertia:?? 54?g-cm2 Detent torque:?? 0.22 kg-cm Number of wire leads:?? 4 Weight:?? 0.24 kg Length:?? 40mm Motor Shaft:?? 5mm Front Shaft length:? 20mmThis item includes:
4 PCS Nema 17 with 4000g.cm, 1.7A current, 4-Leads, 40mm body length, 5mm shaft diameter, 2 phase,
4?PCS JK0220 with 1.7A peak current, 12-36VDC, 128 Microstep
1 PC 200W,24VDC,8.3A Power Supply,
1 PC Breakout board Board & Cable
1, Stepper Motor
Technical Specifications
Part No.:??????????????????????????????????? JK42HS40-1704
Frame Size:??????????? ????????? ???????? ?NEMA17
Step Angle:??????????????????????????????? 1.8 degree
Voltage:?????????????????????????????????? ??3.4V
Current:?????????????????????????????????? ? 1.7 A/phase
Resistance:?????????????????????????????? 2.0 Ohm/phase
Inductance:?????????????????????????????? 3.0 mH/phase
Holding torque:???????????????????????? 4000g-cm????? 56OZ-IN
Rotor inertia:???????????????????????????? 54?g-cm2
Detent torque:?????????????????????????? 0.22 kg-cm
Number of wire leads:??????????? ?? 4
Weight:?????????????????????????????????????0.24 kg
Length:?????????????????????????????????????40mm
Motor Shaft:???????????????????????????? ?5mm
Front Shaft length:?????????????????? 20mm
?We offer customer\'s designed service! If you need special size, please offer us your size requirements, so that we can manufacturer the exact models for you, thanks :)
2, Matching Stepper Motor Driver JK0220 with 1.7A,12-36VDC,12V-24VAC/128Microstep.
Introduction:
JK0220?is a type? of two-phase hybrid stepping motor driver, The drive voltage of which is from 12VDC to 36VDC. It is designed for use with 2-phase hybrid stepper motor of all kinds with 20mm to 42mm outside diameter and less than 2.0A phase current. This circuit that it adopts is similar to the circuit of servo control which enables the motor to run smoothly almost without noise and vibration. Holding torque when JK0220 rund?at high speed is also significantly higher than the other two-phase drivers, what’s more, the positioning accuracy is also higher. It is widely used in middle and big size numerical control devices such as curving machine, CNC machine, and computer embroider machine, packing machines and so on.
Features:
l? High performance, low price
l? Average current control, 2-phase sinusoidal output current drive
l? Supply voltage from 12VDC to 36VDC,12VAC to 24V AC
l? Opto-isolated signal I/O
l? Overvoltage, under voltage, overcurrect, phase short circuit protection
l? 8 channels subdivision and automatic idle-current reduction
l? 8 channels output phase current setting
l? Offline command input terminal
l? Motor torque is related?to speed, but not related to step/revolution
l? High start speed
l? High holding torque?at high speed
More Order quantites, more discount!!!
?Our products are mainly used in robotization, Spinning Automatization, Printing, Packing, Medica?? Machine, Make-up Equipment, Communication,??? Household Appliance, Water Pump, Milling Machine, Engraver Machine, CNC Routers.. etc automatic equipment of various trades.
?We product all kinds of motors & driver. And we can manufacture products according to our customer\'s design.Currently we are looking for qualified stocking distributors with competitive price and good discount in all?United?WORLDWIDE?for mutually beneficial long-term relationship. We try our best to support our distributors and business partners to develop more market percentage.
Please join us, let’s create the glorious future together!
