European Hammer Crusher

Introduction of EuropeanVersion Coarse Hammer Crusher

European Hammer Crusher is engaging in crushing various rocksand stone with comprehensive strength not higher than 320MPa into coarse powderand small particles, it is widely used in metallurgy, mining, chemical, cement,coal, san-making, coal gangue, construction, regratory materials and ceramicindustries.

Advantages of Shanghai ClirikMachinery European version coarse hammercrusher

1.         High capacityand low powder construction;

2.       Uniformparticle size with high crushing and crushing ratio;

3.       Simplestructure;

4.       Easyoperation; low investment.

Working Principle of European versioncoarse hammer

European version coarse hammer mainly consists of frame,rotor, support iron and grate bars. The frame is divided into two parts: upperpart and lower part, which are welded by steel paltes after being cut. Linersmade of high manganese steels within the frame can be replaced after being wornout. The rotors consist of turn plates, pin shafts, and hammers which aregrouped regularly in the main shaft. The main unit drives the main shaftthrough the motor and triangle belts, which, in turn, rotates the rollers.Large materials entering the crusher through the feed inlet are firstly crushedby the high-speed hammers, and then thrown fiercely to the support ironfor further crushing. Qualified materials crushed will be screened out and exitfrom the gap of the grate bars while the unqualified will be left in thecrushing cavity to be further hammered and ground until reach the standardsize. The size of the final product can be adjusted by changing the grate bars.The gap between the rotors and the grate bars can also be adjusted according todifferent requirement. To avoid the plugging of the crusher, the proportion ofwater for the crushing materials is no more than 20%.
