Food Single Rotary Tablet Press 17sets Dies , 22mm Dia And 70KN Max. Pressure

Brand Name	wangqun		Place of Origin	China
Model Number	ZP17E

Delivery Time:7-10 days
Certification:ISO 9001:2000，CE

Food Single Rotary Tablet Press 17sets Dies , 22mm Dia And 70KN Max. Pressure

Quick Detail:

rotary tablet press,tablet press machine automatically continuous rotary tablet press Number of Dies:17sets Max. Pressure:70kn Max Production Capacity:26000pc/h Warranty:1 year

Description:

The machine is an automatically continuous rotary tablet press that are widely used in pharmaceutical, chemical, ceramics, foodstuff , electronics, plastics and powder metallurgy industries , etc. This machine is suitable for pressing round tablets form various kinds of granular materials, and can be also used to press irregular tablets of different geometrical shapes . It is particularly suitable for production of small scale, but not suitable for pressing of semi-solid, wet and ultra-fine powder particles.

During operation, the rotation speed of turntable, the depth of filling material and the thickness of the tablets can be adjusted. Overload protection unit is included in the system to prevent punch dies and apparatus from overload damage. The transmission system installed under the bottom of the machine adopts enclosed immersed lubrication to extends service life and avoid cross-contamination.

Applications:

widely used in pharmaceutical, chemical, ceramics, foodstuff , electronics, plastics and powder metallurgy industries , etc. This machine is suitable for pressing round tablets form various kinds of granular materials, and can be also used to press irregular tablets of different geometrical shapes

Specifications:

Number of Dies	17 sets
Max. Pressure	70KN
Max? Dia. of Tablet	22mm
Max Depth of Tablet	25mm
Max Thickness of Tablet	10mm
Diameter of up and down punch pole	24mm
Thickness of medium mould	28mm
Dia. of medium mould	30mm
Turret Speed	0-26 r/min
Max Production Capacity	23000 pc/h
Overall Size(L*W*H)	820*610*1680mm
Net? Weight	860kg
Motor Power	3kw

Competitive Advantage:

an automatically continuous rotary tablet press suitable for production of small scale Overload protection unit is included in the system pressing round tablets form various kinds of granular materials meet the GMP requirement used in pharmaceutical, chemical, ceramics, foodstuff , electronics, plastics and powder metallurgy industries
