Home > Products > CCTV Power Adapter > Desktop EU / AU Plug Switching CCTV Power Adapter 12V 3A / POS Adapter
Desktop EU / AU Plug Switching CCTV Power Adapter 12V 3A / POS Adapter
- T/T L/C D/P D/A
- 7 days
You May Like
-
3 Pin Uk Plug CCTV AC DC Power Adapter , 12V 1A Transformer 3.5mm x 1.35mm
-
24V 5A 120W DIN Rail Power Supply / AC To DC Switching Power Supply
-
5.5mm 2.5mm AC DC 12V 500ma Power Supply Adapter For Wireless Router / Hard Drive
-
110V - 240V AC To 12V DC 1A Transformer AC DC Power Adapter , LED Power Adaptor
-
US Plug Wall Mount 5V 1A Micro USB AC DC Power Adapter 110v To 220v
-
ODM 7.5 Watt 1500mA / 1.5A AC DC Power Right Angle Plug Adapter 5V
Product Details
| Brand Name | VOTOO | Place of Origin | China | |
| Model Number | VP-1203000 |
Product Description
Certification:CE,ROHS
Desktop EU / AU Plug Switching CCTV Power Adapter 12V 3A / POS Adapter
Quick Detail:
12V 3A switching power supply Type: desktop type Material: ABS AC plug: EU,US,AUS,UK,CN etc. Dc plug: 5.5*2.1mm,5.5*2.5mm,3.5*1.35mm, micro/mini usb etc. Certificate: CE & RoHS OEM/ODM welcomeFeatures:
o Universal Input 100~240VAC 50/60Hz
o Small volume, light weight, high efficiency.
o Cooling by free air convection.
o 100% Full load burn-in test.
o One year warranty.
o Output Voltage: 12V
o Output Current: 3000mA
o Power: 36Watt
o Ripple & Noise: 1% of Output Voltage
o Leakage Current: 0.25mA
o No load power Consumption
o Working Temperature:0-40°C Max
o Efficiency:86%Min
o High Efficiency
o Short Circuit Protection
o Over Voltage Protection
o Over Current Protection
o Green Circuit Design
Weight: 250g
Dimensions: 98.0 x47.0 x 32.0mm
o Accurate information and descriptions.
o All orders are shipped on time.
o All items are fully inspected prior to shipping to meet international standards by our QC staffs.
o All items are with CE RoHS approval to ensure the products quality.
Specification:
?
|
OUTPUT |
DC VOLTAGE |
12V |
|
OUTPUT POWER |
36W |
|
|
CURRENT RANGE |
3000mA |
|
|
INPUT |
VOLTAGE RANGE |
110VAC -264V AC |
|
FREQUENCY RANGE |
50-60Hz |
|
|
EFFICIENCY(Typ.) |
86% |
|
|
ENVIRONMENT |
WORKING TEMP. |
-0°C ~ +40°C (Refer to output load derating curve) |
|
STORAGE TEMP.,HUMIDITY |
-10°C ~ +70°C 10~95% RH |
|
|
COOLING METHOD |
BY FREE AIR CONVECTION |
How to Install?
Before connecting check whether the power supply fullfields electrical specification (output voltage and current). Also check the socket type and its polarity. Connect power supply to the supplied unit. Power supply must be connected to a working electrical AC line with a voltage of 100-240V. Do not install power supply in locations with high humidity, dust or strong direct sunlight. The power supply should be installed in a location with good airflow. Power supply can only be installed indoors. AC wire should connect tight with adapter socket, in case poor contact socket.
?
?
Applications:
1. CCTV security, door access, digital camera, etc.
2. POS machine, mini printing machine, etc.
3. Electronic scale, flowerpot etc.
4. LED strip, LED lighting etc.
