Switching Desktop Power 12V 8A Adapter For LED Strip , Micro USB Adapter

Brand Name	VOTOO		Place of Origin	China
Model Number	VP-1208000

Delivery Time:5-10 days
Certification:CE,ROHS

Switching Desktop Power 12V 8A Adapter For LED Strip , Micro USB Adapter

Quick Detail:

Type: desktop type Desktop 12V 8A Switching Power Adapter Dc plug: 5.5*2.1mm,5.5*2.5mm,3.5*1.35mm, micro/mini usb etc. No load power consumption< 0.3W 100% aging test before shipment 100% spot check before shipment Certificate: CE & RoHS OEM/ODM welcome

Features:

o Universal Input 100~240VAC 50/60Hz

o Small volume, light weight, high efficiency.

o Cooling by free air convection.

o 100% Full load burn-in test.

o One year warranty.

o Output Voltage: 12V

o Output Current: 8A

o Power: 84Watt

o Ripple & Noise: 1% of Output Voltage

o Leakage Current: 0.25mA

o No load power Consumption

o Working Temperature:0-40°C Max

o Efficiency:86%Min

Protections

1)over voltage protection: 120%min
2)over current protection: 120%min
3)over protection

4Short-circuit protection: automatic recovery -

5Load regulation: ±5%

Environmental requirement

1)operating temperature: 0-40

2)storage temperature: -20-85

3)opera ting relative humidity:595%RH

4) Withstanding voltage: AC 3,000V (minimum), 5mA (maximum)

-

5) Insulation resistance: DC 500V 100MΩ (minimum) -

Weight: 380g

Dimensions: 140*60.5*34.5mm

1. AC input power suitable for the world2. Soft-start current can reduce the AC input impact efficiency

3. With short-circuit and overload protection

4. Compact size ,light weight

5. 100%full-load burning test

6. Installed with EMI filter ,minimum wave

Specification:
?

InPut Charactoritics

Output power(max): 1-120W

Input voltage : 100-240Vac

Input frequancey: 50-60hz

Output Charactoritics

Output Voltage: 12V

Output Amp: 8A

Output Watt: 96W

Condition: Brand New

OEM equivalent part, 100% compatible as genuine part!

How to Install?

Before connecting check whether the power supply fullfields electrical specification (output voltage and current). Also check the socket type and its polarity. Connect power supply to the supplied unit. Power supply must be connected to a working electrical AC line with a voltage of 100-240V. Do not install power supply in locations with high humidity, dust or strong direct sunlight. The power supply should be installed in a location with good airflow. Power supply can only be installed indoors. AC wire should connect tight with adapter socket, in case poor contact socket.

?
?
Applications:

1. CCTV security, door access, digital camera, etc.

2. POS machine, mini printing machine, etc.

3. Electronic scale, flowerpot etc.

4. LED strip, LED lighting etc.
