OEM 8ch H.264 Mobile DVR Recorder ADPCM Audio With Embedded Linux OS

FOB Price

Negotiable / Kilogram

1 Kilogram(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Fortunemount		Place of Origin	China
Model Number	MDVR-D3308

Delivery Time:2 weeks based on sales forecast and 1 month without any sales forecast
Certification:CE, ROHS, FCC

OEM 8ch H.264 Mobile DVR Recorder ADPCM Audio With Embedded Linux OS

Features:

·Using H.264 Compression algorithm, high compression ratio, image more clearly;

·With 8-36 V wide voltage design, for all kinds of automobiles;

·Support 8 channels input , can monitor more positions;

·Using special file management mechanism, it can encrypt the data, and effectively protect data security;

·Using particular error scan technology of the hard disk, it can ensure the continuity of recording, and also prolong the hard disk life

·With dual streaming technology, it can ensure the effect of local video recording, and also ensure the wireless transmission effect;

·Support recording to SD card and hard disk at the same time;

·Support to overlay some vehicle informations, such as the stops information, speed, brake signal, and door open or closed signal;

·support 1*SATA hard disk and 1*SD Card Storage;(HDD Maximum 1T, SD Maximum 32G)

·Optional Wifi;

·Optional 3G(support? EVDO & WCDMA);

·Optional GPS.

Specification:

	Model	MDVR-D3308
Project	Device parameter	Performance
System	Processor	Hi3515
OS	Embedded Linux OS
Operating language	Simplified/En/Traditional
Operator interface	GUI, support mouse
Safety management	User password, Admin password in two layer management system
Video	Video standard	PAL(625 lines,50 scenes/sec);NTSC(525lines,60 scenes/sec)
Compression	H.264(Main Profile)
Live view quality	D1
Playback quality	CIF/D1
Encoding capacity	2D1+6CIF realtime; 8CIF realtime
Decoding capacity	4D1 realtime
Input	8 channel composite video input
Output	2 channel composite video output
Display	Single picture, 4 pictures, 8 pictures, 9 pictures; alarm screen automatic switch
Audio	Compression	ADPCM
Input	8 channel audio input
Output	1 channel audio output
Recording mode	Video and audio synchronously recording
Speech talkback	Supported
Recording & playback	Recording type	Manual,Schedule,Alarm,Circle recording
Video bitrate	64Kbps~1.5Mbps
Audio bitrate	8KB/s
Storage medium	Support 1 SD card and 1 SATA hard disk
