HT 840 Colored Metal Panel Arch Steel Curving Roll Forming Machine
- T/T L/C D/P D/A
- 7 days
You May Like
-
4m Color Steel Sheet Hydraulic Shearing Cutting Machine / Sheet Metal Cutter
-
CNC Cold 45# Steel Wall Panel Roll Forming Machine 3KW With PLC
-
Decoiler Straightener Feeder And Uncoiler Machine 5T For Uncoilling Steel Coil
-
Metal Sheet Uncoiler Machine For Supporting And Uncoiling The Steel Coil
-
Popular Roof Panel Corrugated Roll Forming Machine With Color Steel 9 M/Min
-
Automatic Steel Coil Uncoiler To Decoiling 11kw , Sheet Cutting Machine
Product Details
| Brand Name | HuaTong | Place of Origin | China | |
| Model Number | HT 840 arch plate roll forming machine |
Product Description
Certification:ISO9001:2000
HT 840 Colored Metal Panel Arch Steel Curving Roll Forming Machine
1. Name of production line:?
HT-840 ?type curving machine
|
Name |
?curving machine |
Application |
Roof |
|
Warranty |
1 year |
Feature |
1.High quality |
|
Color |
Any |
Certificate |
ISO9001:2000 |
Description
|
Condition |
New |
|
Type |
840 curving machine |
|
Tile Type |
Colored Steel |
|
Use |
Roof |
|
Power(W) |
1.5KW |
|
Voltage |
380V |
|
Dimension(L*W*H) |
1.3M*0.8M1.4M |
|
Certification |
ISO |
|
Warranty |
1year |
|
After-sales Service Provided |
Engineers available to service machinery overseas |
|
Color |
any |
|
Material of frame |
(high grade)300mmH shape steel welding |
|
Thickness of middle plate |
25mm |
|
Step of curving roller |
5 piece |
|
Diameter of shaft |
74mm |
|
Voltage |
380v |
|
Certificate |
ISO9001:2008 |
|
Warranty |
1 year |
2. parameters of roll forming machine
(1). Material of frame : (high grade) 300mm H shape steel welding
(2).Thickness of middle plate : 20mm
(3). Step of curving roller : 7 steps
(4). Diameter of shaft (solid shaft): 74mm
(5). Material of shaft (solid shaft): (high grade) 45# Steel,quenching and tempering treatment
(6). Material of roller: 45# Steel
(7).Treatment of roller : hard chromize coated
(8). Drive type of roll forming machine : drive by hydraulic motor
(9). Bearing : 6210 (high grade)
(10). Power of main motor : 1.5KW
(11). Voltage : 380V/50Hz/3phase
(12). Motor power of hydraulic station : 3kw
(13). Oil pump of hydraulic station : gear oil pump (high grade)
(14). Accuracy of curving : 2mm
(15). Appearance size of main forming machine : 1.3m (length)*0.8m (width) *1.4m (height)
(16). Electrically controlled system : entire machine controlled by PLC
(17). PLC: DELTA(TAIWAN)or Mitsubishi
(18). Controlling desktop : Touch screen (high grade)
(19). Electrical parts : DELIXI or CHINT
