Portable 4200MAh 15 days standby easy use no installing car gps tracker system long battery life gps

Portable 4200MAh 15 days standby easy use no installing car gps tracker system long battery life gps

tracker

This tracker can add a waterproof bag also it can add a magnetic for attaching.

1 Introduction

This product is based on GSM / GPRS network and GPS satellite positioning system, short message or contact each other through the remote targets or monitoring, is the most technologically advanced GPS and AGPS double positioning, built-in high-capacity battery, long standby 15 days, strong magnetic adsorption free installation of portable GPS locator.
?

2 Applications

3 Hard ware ??

4 Specifications Description

5. Note

Attention pls

5.1 SIM card setting

Please make sure your SIM card is no call transfer and call display and PIN code off. SMS must be in plain text format, does not recognize the PDU format.

5.1.1 Open the SIM card chip soft stuffed ?5.1.2 SIM card slot ????????????????5.1.3 advancing down soft plug cover ????????????????????

5.2 Battery and Charger
When charging the battery for the first time, please charge 8-12 hours. Please use the manufacturer unified configuration and battery charger, standard battery is a lithium battery, and can be fully charged in about 720 hours standby normal, normal state of battery charge time is 3-5 hours.

Letter:
a: The Li-ion battery contains harmful chemicals and may burst, please do not bump, puncture it and into the fire.
b: Please charge it in time to keep it working normally.

5.3Start Unit

1.SIM card is inserted properly
2.The unit outdoors and turn on the key, until the lights are on.
3.In the first use, please initialize to their default settings. (Please refer to the User Manual 5.4)
4.In 10-40 seconds, the device will search for GSM and GPS signals and begin normal work under normal status indicator devices will remain flashing once every 3 seconds.
5.When this unit receives GPS signals normally, you can use it and any one instruction set

?5.3.1 Green Light:GPRS
