Home > Products > Portable GPS Tracking Device > Portable GPS Tracking Device Automotive Fuel Sensor GPS Tracker Long Standby
Portable GPS Tracking Device Automotive Fuel Sensor GPS Tracker Long Standby
- T/T L/C D/P D/A
- 7 days
You May Like
-
Asset Tracking Device Children Quad Band SMS GSM GPS Tracker
-
GPS Car Tracker System Real Time Car Gps Tracker With Camera Fuel Sensor And Temp Sensor
-
Newest Gps Tracker Device 3G WCDMA GPS Tracker Sytem for Car / for Truck / for Ambulance And for Bus
-
OBD2 Gps Tracking Device Portable OBD2 GPS Tracker for Car Produced After Year-2000
-
SPY Tracking Device Mini Quad Frequency Car GPS Tracker System With GSM SIM 9 - 70V Voltage Google g
-
SPY Tracking Device 1000MAh Battery IPX6 Mini Waterproof Car GPS Tracker G-t011 With System For Safe
Product Details
Brand Name | GH | Place of Origin | China | |
Model Number | G-T500 |
Product Description
Certification:CE ROHS
Portable gps tracking device 1000 Days car GPS tracker designed for fixed asset tracking applications systemsG-T500
Hibernating Asset Tracking Device
Attention:For this unit we do not offer platform,you need? to got your own tracking server,while we can offer protocol and guide you how to analyze the protocol.
Product Description:?
The G-T500 is a powerful GPS tracker designed for fixed asset tracking applications. It is powered by two user replaceable CR123A lithium batteries. Configuration allows it to wake up on a preset schedule to check if it needs to shift from dormant to active status and/or send update of its current location, then returning to a dormant state. Optimally configured, it will operate autonomously for 1000 days. Its built-in 3-axis accelerometer allows the G-T500 to detect asset movement and transmit an alert message. The integrated @Track interface protocol allows the G-T500 to communicate with a customer mobile phone or a backend server via GPRS/SMS and transfer reports of GPS position, etc. System integrators can easily incorporate the G-T500 into existing tracking systems based on this full featured protocol.
Features
Frequency? |
Quad band: 850/900/1800/1900 MHz Compliant to GSM phase 2/2+ -Class 4 (2W @ 850/900 MHz) -Class 1 (1W @ 1800/1900 MHz) |
GPRS |
GPRS multi-slot class 10 GPRS mobile station class B |
RMS Phase Error |
5 deg |
Max Out RF Power |
GSM850/GSM900: 33.0±2 dBm DCS/PCS: 30.0±2 dBm |
Dynamic Input Range |
-15?~ -108?dBm |
Receiver Sensitivity |
Class Ⅱ RBER 2% (-107 dBm) |
Stability Of Frequency |
< 2.5?ppm |
Max Frequency Error |
±0.1?ppm |
GPS Chipset |
u-blox All-In-One GPS receiver |
Sensitivity |
Autonomous: -148 dBm Hot start: -160 dBm Tracking: -162 dBm |
Position Accuracy |
Autonomous: < 2.5m SBAS: 2.0m |
TTFF (Open Sky) |
Cold start: 30s average Warm start: < 30s Hot start: < 1s |
Audio |
Internal microphone |
GSM ?Antenna |
Internal only |
GSM ?Antenna |
Internal only |
Internal Indicator LED |
GSM, GPS and battery status |
Serial Port |
Internal 8 pin connector for upgrading or debugging |
Dimensions |
80mm*58mm*26.8mm |
Weight |
65g (without batteries) |
Batteries |
Two CR123A lithium batteries 1500 mAh |
Standby Time |
Standby current: < 10 uA SMS count: 1000 SMS SMS reporting standby: ? ? ???? One SMS report per day: 1000 days TCP reporting standby: ? ? ???? One report per day: 950 days ? ? ? ?? Four reports per day: 248 days ? ? ? ?? Five minutes reporting: 4 days |
Operating?Temperature |
-20℃?~ +60℃ |
Comma |
