Product Details
| Brand Name | HONGFENG920 | Place of Origin | China | |
| Model Number | TB5 TB11 |
Product Description
Low Pressure Bimetallic Steam Trap
?
Quick Details:
Temperature: 425 ℃
Working Media: Steam, Condensate Water
End Connection: Flange, Screw & Socket Welded
Adjustable Discharging Temp
?
Specifications:
Thermostatic Steam Traps
Tight Shut-off With SCCV System
Adjustable Discharging Temp
Water Seal No Steam Loss
Installed In Any Direction
Design Pressure: PN25
Preesure: 0.01 - 1.6 Mpa
Material: WCB & A105
Temperature: 425 ℃
Working Media: Steam, Condensate Water
End Connection: Flange, Screw & Socket Welded
Bimetallic Steam Trap / Thermostatic Steam Trap
TB11:
1. Tight shut-off and long service life by using SCCV system. 2. Efficient in energy saving---adjustable discharging temperature And effectively using the sensible heat of hot condensate. 3. Discharging temperature can be adjusted when the pipe net is in Operation. Can be installed in any direction. 4. Hot condensate exists just before the trap, forming a tight water Seal, which ensures no steam loss. 5. Withstands water hammer with outstanding performance of air Venting. 6. Operating without noise, benefiting for environmental protection. 7. Full open at the beginning of steam supplying, discharging cold Condensate and air rapidly, which ensures quick start-up. 8. Stainless steel internals are resistant to corrosion and cavitation. Small in size and light in weight, easy maintenance.?
Application:
This steam trap is suitable for steam main pipe, steam tracer, radiator, low temperature heating trough, jacketed kettle and heating system etc...
Note:
This steam trap\'s Insulation is not recommended for pipe section 1 meter before the trap and the trap itself.
