Built In Strainer Mechanical Steam Trap Large Capacity 0.05 6.5 Mpa

Built In Strainer Mechanical Steam Trap Large Capacity 0.05 – 6.5 Mpa

Structure:Free Float Steam Trap?????????

Pressure:0.05 - 6.5MPa???????????

Media:? Steam, Water????????????

Materials:WCB, WC6?????????

End Connection:? Flange ????

Specifition:

Free Float Steam Trap
Free Float Pilot Mechanism
Heavy Discharge Capacity
Built-in Strainer
All Internals Repaired Easily

Hongfeng920?ball float steam trap works efficiently on both light and heavy condensate loads.

Ball Float Steam Trap / Lever Float Steam Trap

Model:

JH10, JH15

Features:

1. Free float pilot mechanism ensures no backing-up of condensate.
2. Piston valve opens smoothly with?extremely large?discharge capacity.
3. Steam cushion prevents slamming of main valve on to seat.
4. All internal parts are easily accessible without having to remove the trap from the line.
5. Built-in strainer with large surface area for reliable protection.

Application:?

JH10 float steam trap is suitable for steam main pipe, steam tracer and steam heating equipment of high temperature and pressure, saturated steam and over heated steam. JH15 ball float steam trap is suitable for steam equipment of middle-high pressure heating, drying, fractionation and facilities where large quantity of condensate is produced.
