High Resolution Full Color With IP65 /54 Commercial Led Display for advertising/stage/commercial
- T/T L/C D/P D/A
- 7 days
You May Like
-
Portable 60HZ Waterpr Energy Saving Commercial Led Display /Screen/Video wall for public concert
-
Commercial DIP Outdoor Full Color Curved LED Screen IP65 P16 For Shopping Mall 16 bit , 60HZ
-
Full Color P16 Outdoor LED Curtain Display Billboard for Shopping Center , Energy Saving
-
Advertising P16 Outdoor LED Display , 1R1G1B 9800Cd/ DIP Curved LED Screen For Airport
-
1R1G1B1W DIP Rental LED Video Wall , P12 Outdoor Curved LED Screen / Display for Stadium
-
Static P16 Outdoor Flexible LED Curtain Display Screen Rental For Advertising 3906 pixels/
Product Details
Brand Name | GLIANG | Place of Origin | China | |
Model Number | GLIANG |
Product Description
Certification:CE, CCC, FCC, ROSH, ISO9001
High Resolution Commercial Led Display Full Color With IP65 /54
Quick Detail:
MTBF(hrs) : 1000 The whole screen perspective : H:135°;V:55° low power consumption, high brightness, long life and good video effect. It can establish at business square, sports stadium, airport and station, highway etc.Description:
BVO series ultra low power outdoor LED display or LED screen are new products with XIWAN new technology. Xiwan have invested millions of dollars on this new technology. Dedicate to save energy cost for big LED display and improve image quality very effectively. We have now developed P10, P12, P16, P20 and P25, you can choose according to your own applications.
Qualified LED core from Epistars, Silan and other big brand.
Qualified LED driving from Meanwell
Applications:
Advertising media, sports stadiums, airport station, business establishments, and public square
Specifications:
Item No. |
BVO-P12 |
Pixel Pitch(MM) |
P12 |
Module resolution |
16*16 |
Module size(MM) |
192*192 |
Pixel combination |
DIP 1R1G1B1W |
Pixel density |
6944 pixels/㎡ |
Driving way |
1/4 Scanning |
Cabinet size(MM) |
960*960 |
Cabinet resolution |
80*80 |
Cabinet pixel |
6400 |
The number of modules |
25 |
Cabinet type |
Fixed installation water proof iron box |
Cabinet weight (Kg) |
55 |
Average Power Consumption (W/㎡) |
≤160W/㎡ |
The maximum power(W/㎡) |
≤320W/㎡ |
Brightness (Cd/㎡) |
9500 |
Gray scale |
16bit(4096 levels) |
Refresh rate |
≥800 |
Brightness adjustment |
256 levels |
Frame frequency |
60HZ |
Input voltage |
110~220VAC |
Working temperature |
-20℃~+50℃ |
Work humidity |
10%-90%RH |
Best stadia |
≥12m |
The whole screen perspective |
H:135°;V:55° |
IP rating |
Front:IP65;Back:IP54 |
MTBF(hrs) |
1000 |
Life span(hrs) |
100000 |
Competitive Advantage:
Why Choose BVO ultra low power LED display?? 5 advantages of our product
●50% energy savings
Up to 50% reduction in energy consumption, in special circumstances, even more than 70%, it reduced the use-cost and greenhouse gas emissions greatly.
Take BVO-20 LED display as example, compared with ordinary products, per square meter can save energy over 160W for 1 h, a 100m2 screen works 24 hours per day, 365 days per year, it can save energy =(160W×100m2×24h×365)/1000 =140,160KW (KWH), reducing greenhouse gas emissions 106,241kg
●30% longer service life
30% longer service life than the competitors. Our proprietary technology ma
