Home > Products > Curved LED Screen > High Brightness Outdoor P12 LED Display Board For Highway With Long Life Time AC 110V - 220V
High Brightness Outdoor P12 LED Display Board For Highway With Long Life Time AC 110V - 220V
- T/T L/C D/P D/A
- 7 days
You May Like
-
DIP P12 Outdoor Advertising Led Display Screen , Full Color Curved LED Screen 960*960mm
-
Outdoor DIP P12 Flexible DIPLED Curtain Display Rental for Sports Stadium , Low Power Consumption
-
Low Power Consumption Silan Full Color Commercial Led Display / Video Wall/sign For Rental /stage
-
High Resolution Full Color With IP65 /54 Commercial Led Display for Advertising/stage/commercial
-
Portable 60HZ Waterpr Energy Saving Commercial Led Display /Screen/Video Wall for Public Concert
-
Commercial DIP Outdoor Full Color Curved LED Screen IP65 P16 For Shopping Mall 16 Bit , 60HZ
Product Details
Brand Name | GLIANG | Place of Origin | China | |
Model Number | GLIANG |
Product Description
Certification:CE, CCC, FCC, ROSH, ISO9001
High Brightness Outdoor P12 LED Display Board For Highway with Long Life time AC 110V - 220V
Quick Detail:
Pixel Pitch(MM) : P12 The number of modules : 25 Refresh rate : ≥800 BVO-12 outdoor full color LED display/LED screen is suitable for commercial and advertising display with advantages of wide color gamut, High resolution, less power consumption, high brightness and long lifetime.Description:
BVO series ultra low power outdoor LED display or LED screen are new products with XIWAN new technology. Xiwan have invested millions of dollars on this new technology. Dedicate to save energy cost for big LED display and improve image quality very effectively. We have now developed P10, P12, P16, P20 and P25, you can choose according to your own applications.
Qualified LED core from Epistars, Silan and other big brand.
Qualified LED driving from Meanwell
Applications:
Advertising media, sports stadiums, airport station, business establishments, and public square
Specifications:
Item No. |
BVO-P12 |
Pixel Pitch(MM) |
P12 |
Module resolution |
16*16 |
Module size(MM) |
192*192 |
Pixel combination |
DIP 1R1G1B1W |
Pixel density |
6944 pixels/㎡ |
Driving way |
1/4 Scanning |
Cabinet size(MM) |
960*960 |
Cabinet resolution |
80*80 |
Cabinet pixel |
6400 |
The number of modules |
25 |
Cabinet type |
Fixed installation water proof iron box |
Cabinet weight (Kg) |
55 |
Average Power Consumption (W/㎡) |
≤160W/㎡ |
The maximum power(W/㎡) |
≤320W/㎡ |
Brightness (Cd/㎡) |
9500 |
Gray scale |
16bit(4096 levels) |
Refresh rate |
≥800 |
Brightness adjustment |
256 levels |
Frame frequency |
60HZ |
Input voltage |
110~220VAC |
Working temperature |
-20℃~+50℃ |
Work humidity |
10%-90%RH |
Best stadia |
≥12m |
The whole screen perspective |
H:135°;V:55° |
IP rating |
Front:IP65;Back:IP54 |
MTBF(hrs) |
1000 |
Life span(hrs) |
100000 |
Competitive Advantage:
● Wide color gamut
Xiwan technology is bio-mimetic; it optimizes the match of display technology to the biological mechanisms of human vision,
Increase color gamut by 10-20% , and improve the image!
5 advantages of XIWAN BVO series of low power consumption product:
●High resolution
Achieve higher resolution while using an equal number of the pixels. it based upon extensive knowledge of the human vision system and our unique pixel layouts and proprietary algorithm, in Xiwan displays, individual pixels are not restricted to use in one pi
