10Base-T, 100Base-TX Single Mode 1550nm Fiber Optic Media Converter Gigabit 1-fx to 1-Rj45

Technical Parameter:

Access Method:

10/100/1000Mbps

Standard:

IEEE802.3, IEEE802.3u, IEEE802.3ab , IEEE802.3z , IEEE802.1q, IEEE802.1p, IEEE802.1d

Wavelength:

850nm/1310nm/1550nm

Distance:

Dual Fiber MM : 550m
Dual Fiber SM : 10/20/30 /50/80Km ,
Single Fiber SM : 20/40/60Km
CAT5 : 100m

Conversion Method:

Media Conversion

Time Delay:

<10us

BER:

<1/1000000000

LED Indicator Lamps:

1000M , 100M , FX LINK/ACT, TP LINK/ACT, FDX, POWER

Power Supply:

DC5V 1A (external power) , AC220 0.5A /DC-48( internal power )

Power Dissipation:

3W

Operating Temperature:

0 ~ 50 ℃

Humidity:

10/100/1000Mbps

Storage Temperature:

5%~90%

Storage Humidity:

-40~ 70 ℃

Dimension:

5%~90% non-condescending

Model No.

Description

FR-1201S05

10/100/1000M Multi-mode 1310nm 550M

FR-1201S20

10/100/1000M Single-mode 1310nm 20km

FR-1201S40

10/100/1000M Single-mode 1310nm 40KM

FR-1201SA20

10/100/1000M Single-mode WDM 1310/1550nm 20km

FR-1201SB20

10/100/1000M Single-mode WDM 1550/1310nm 20km

FR-1201SA40

10/100/1000M Single-mode WDM 1310/1550nm 40km

FR-1201SB40

10/100/1000M Single-mode WDM 1550/1310nm 40km
