Horizontal Single Side Stator Winding Lacing Machine Stator OD 175mm ~ 300mm
- 0 Case / Cases per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Automatic Armature Trickle Impregnation Machine / Equipment With Air Cooling
-
High Precision Stator Trickle Impregnation Machine For Household Electrical
-
Three phase Armature Winding Machine / Equipment For Meat Grinder , Mixer Motor
-
Automatic Ceiling Fan Stator Winding Machine / Machinery For External Armature
-
OD 40mm ~ 80mm Rotor Automatic Aluminum Die Casting Machine / Machinery
-
AC Servo Motor Coil Insertion Machine / Automatic Armature Winding Machine
Product Details
| Brand Name | Nide | Place of Origin | China | |
| Model Number | BXIW1-260/300 |
Product Description
Certification:None
Horizontal Single Side Stator Winding Lacing Machine Stator OD 175mm ~ 300mm
Quick Detail:
Description:
The horizontal single side stator winding lacing machine adopts industrial PLC, human-computer interface and horizontal frame-structure design, the servo system machine accurately controls the lacing action. Different lacing methods such as slot-by-slot lacing, interval lacing and fancy lacing are programmable. This horizontal single side stator winding lacing machine is suitable for the big stator with high winding over-hang. The tooling is movable, and convenient for stator fast laoding and unloading, hence to reduce the labor strength effectively.
Technical parameter:
|
Stator I.D |
110~210mm |
|
Stator stack height |
100~260mm |
|
Stator O.D |
175~300mm |
|
Over-hang height |
20~65mm |
|
Slot number |
8~48 slots |
|
Power source |
AC 220V±10% 50/60Hz |
|
Total power |
0.75KW |
|
Weight |
450Kg |
|
Dimension |
1160*1200*1500mm |
Competitive advantages:
The tooling is movable, and convenient for stator fast laoding and unloading.
