Product Details
| Brand Name | Nide | Place of Origin | China | |
| Model Number | BXIL1－100/135 |
Product Description
Certification:None
Inuction Motor Stator Single-head Winding Lacing Machine vertically
Quick Detail:
Description:
Stator is loaded on Single-head Winding Lacing Machine vertically; PLC programming; single-needle and single-side automatic lacing; needle transpositioning, hooking are controlled by servo system; spindle adopts frequency speed control; slot by slot lacing, intercal lacing, and fancy lacing could be achieved by setting in human-machine interface; especially apply to multi sizes, low output or more lead stator winding lacing.
Applications:?
This machine is suitable for stator which meet the below specification.?
Technical Data:
|
1.Stator ID |
φ35-φ120 |
|
2. Stator lamination thickness |
10-100mm |
|
3. Max winding height |
40MM |
|
4. Lacing speed |
0.7S/slot |
|
5. Power |
220V 50-60HZ |
|
6. Air pressure |
?>0.4mpa |
Competitive advantages:
This machine is easy for operation.?
