Home > Products > Button Drill Bit > 4.5 Inch Rock Button Drill Bit , ST58 Spherical CNC Milling Drill Bits
4.5 Inch Rock Button Drill Bit , ST58 Spherical CNC Milling Drill Bits
- T/T L/C D/P D/A
- 7 days
You May Like
-
Tungsten Carbide Button Drill Bit ST58 4 Inch / 3.5 Inch hardened steel drill bits
-
Spherical Bench / Long Hole Tungsten Carbide Drill Bit Set 4-6 Inch
-
105mm 110mm ST68 Ballistic Button Drill Bit Wear Resistance Metal Drill Bit
-
R25 Tungsten Carbide Drill Coupling With CNC Milling 155-160mm
-
R25 Mining Crossover Coupling Rock Drilling Tools 150-170mm
-
CNC Milling Drill Coupling R28 Threaded Coupling Wear Resistance
Product Details
| Brand Name | MIROC | Place of Origin | China | |
| Model Number | 4148300965-972 |
Product Description
4.5 Inch Rock Button Drill Bit , ST58 Spherical CNC Milling Drill Bits
Description
This type of bit is well known for its high wear resistance on medium-hard to hard abrasive rock formations (between 200 Mpa to 260 Mpa compressive strength). Featuring spherical tungsten carbide inserts that is known to have strong configuration against carbide fracture.
.
? Widely used in bench and long hole drilling
? Bit face design is ideal for medium-hard to hard abrasive rock
Color: Green or Based on Customer requirements
Material: Tungsten carbide and high strength alloy steel
Processing: CNC milling and proprietary heat treatment process
Type: ST58 Button Bit Spherical Buttons
Applications
? Underground mining
? Tunneling
? Quarry
Competitive Advantage
? High grade tungsten carbide inserts
? Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment
specification
| Part?Number | Bit?Diameter?(mm) | Bit?Diameter?(inch) |
Front?Buttons? (No.?x?mm) |
Gauge?Buttons? (No.?x?mm) |
| 4148300965 | 89 | 3?1/2 | 6x12 | 8x12 |
| 4148300966 | 89 | 3?1/2 | 6x13 | 8x13 |
| 4148300967 | 89 | 3?1/2 | 4x13,?1x13 | 8x13 |
| 4148300968 | 89 | 3?1/2 | 4x12,?2x12 | 8x12 |
| 4148300969 | 95 | 3?3/4 | 4x13,?1x13 | 8x14 |
| 4148300970 | 102 | 4 | 6x14 | 8x14 |
| 4148300971 | 102 | 4 | 6x13 | 8x16 |
| 4148300972 | 115 | 4?1/2 | 6x14 | 8x16 |
| Product?Code?and?Brief?Description | Angle |
Front?Flushing? Holes |
Side?Flushing? Holes |
Weight? (kg) |
| B1489-ST58-S-1,?ST58?Button?Bit,?Spherical?Buttons | 35° | 2 | 1 | 4.1 |
| B1489-ST58-S-2,?ST58?Button?Bit,?Spherical?Buttons | 35° | 2 | 1 | 4.1 |
| B1389-ST58-S-1,?ST58?Button?Bit,?Spherical?Buttons | 35° | 4 | - | 4.1 |
| B1489-ST58-S-3,?ST58?Button?Bit,?Spherical?Buttons | 35° | 4 | - | 4.1 |
| B1389-ST58-S-2,?ST58?Button?Bit,?Spherical?Buttons | 35° | 4 | - | 4.6 |
| B1489-ST58-S-4,?ST58?Button?Bit,?Spherical?Buttons | 35° | 2 | - | 6 |
| B1489-ST58-S-5,?ST58?Button?Bit,?Spherical?Buttons | 35° | 2 | 1 | 6 |
| B1489-ST58-S-6,?ST58?Button?Bit,?Spherical?Buttons | 35° | 2 | - | 7 |
