2.1mm AC 240V To DC 12V 2A Switching LED Power Adapter For CCTV , 50 / 60Hz

2.1mm AC 240V To DC 12V 2A Switching LED Power Adapter For CCTV , 50 / 60Hz

Quick Detail:

Features:

AC Input Detail:

1)AC Input Voltage Range: 100-240V

2)AC Input Current: 600mA

3)Input Frequency Range: 47-63Hz

4)No Load Power Consumption: <0.5W

5)Inrush Current: 30A

6)Hold Up Time 5ms Min.at100Vac input and output Max .Load.

7)Rise Time: 30 ms Max

8)Line Regulation: ±2%

9)Leakage Current: < 0.25mA

1)DC Voltage Range: 12V

2)DC Current Range: 2A

3)Total Regulation:

4)Ripple & Noise: 100 m Vp-p

5)Working Efficiency: 80%

6)Protections: Short Circuit Protection Over Voltage Protection Over Current Protection Open Circuit Protection

7)Weight: 160g

8)Dimensions: 87.0 x 48.0 x 31.0mm

1)Operating Temperature: 0°C -- +40°C

?2)Storage Temperature: -10°C -- +55°C

3)Operating Humidity: 5%(0°C)~90%(40°C) 72h Full Load

4)Storage Humidity: 3%-98%

??Reliability:

1)MTBF( Mean Time Between Failures): 50000 Hours ( Based on MIL-STD-217F)

2)Period of Guarantee and Warranty: 1 year?

1.Best quality:we have the most professional and experienced engineers and strict QA and QC System

2.Best Price:Products are produced in our factory,so we are entitled to control the quality well and reduce?

the cost to offer more competitive price and excellent quality.

3.Strong production capacity:over 200000 pieces per months.

4.Prompt delivery time:3-5 working days.

5.Professional technological team: Your tailored/customized connectors and package are welcome.

6.Good after_sales service: 1 year warranty.

7.Leading supplier:we have more than 10 years experiences in power supply industry.
?

Specification:

How to Install?

applications:

1. CCTV security, door access, digital camera, etc.

2. POS machine, mini printing machine, etc.

3. Electronic scale, flowerpot etc.

4. LED strip, LED lighting etc.
