High Resolution SMD P4 Indoor Full Color LED Display Video Wall Rental for Stage

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	TeehoLED		Place of Origin	China
Model Number	CE, 3C , RoHS, ISO,FCC,UL

Product Description

Delivery Time:15-20days
Certification:CE, 3C , RoHS, ISO,FCC,UL

Quick Detail:

1.High definition;????

2. Easy connection and disassembling;???

3. Wide application, good for rental or fixed installation;?

4. High resolution and high frequency dynamic image.

High Resolution SMD P4 Indoor Full Color LED Display Video Wall Rental for Stage

Description:

1. P4 led display provide personalized solution according to actual request of customer;

2. Wide viewing angle: 120 degree both at horizontal and vertical line, no picture change, no color excursion;

3. 281 trillion kinds of color expression capability, 4000HZ refresh rate, eliminate stroboscopic, can achieve perfect image shooting;

4. Powerful image processing functions, RGB three color brightness, contrast, Gamma curve, each parameter adjustable;

5.Adopt reliable aluminum cabinet, solve heat dissipation problem of high density board from design.

Applications:

? ? ? ? ? ? ?Shopping Malls

???????????? Music Venues and Concerts

???????????? Large Offices

???????????? Theater and Arts

???????????? TV Shows

???????????? Car Shows

Specifications:

Part Number	Teeho-P4-W
Resolution	64(H)×32(V)
Pixel Pitch	4mm
LED Configuration	1R1G1B 3-IN-1 SMD
Pixel Density	62,500 pixels/ ㎡
Module Size	256*128mm
Driving IC	MBI5020
Driving Method	1/16 Scan, Constant Current
Cabinet Weight	42kg/sq.m.
Mechanical Ratings
Hanging Weight Support	2T
Surface Flatness	Gap<0.5mm
Optical Ratings
Brightness	>1,200cd/ ㎡
View Angle	120°/90°
Gray Scale	8bits input, correction with 14bits
Display COLOR	16.7M
Brightness Adjustment	0～100%
Power Supply
Operation Power	90～260V 50～60Hz
Max. Power Consumption	2200W/ ㎡
Average Power Consumption	1100W/ ㎡
Control System
Control Mode	Synchronous display with control PC by DVI
Frame Update Frequency	60～85Hz
Screen Refresh Frequency	300～1000Hz
Gamma Correction	-5.0～+5.0
Support Input	Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI
Control Distance	Ethernet cable<120m or Fiber Optic<10Km
Support VGA Mode	1024×768, 1280×1024, 1600×1200, 1920×1280
Brightness Correction	Pixel, Module, Cabinet
Environmental
Operating Temperature
