P5 Full Color 1R1G1B 3-IN-1 SMD Indoor Rental Led display
- T/T L/C D/P D/A
- 7 days
You May Like
-
P6 Wall Stadium Rental LED Display Screen , Advertising Led full color Display
-
Indoor 1R1G1B 3-IN-1 SMD P7.62 Slim LED Rental Display For Television Relay
-
P4 Super Slim 3-IN-1 MBI5024 IP43 Rental LED Display Screen With 8 Bit Input
-
P4.8 Light Weight Indoor Full Color LED Display Board , Module 288 * 288mm
-
P5 Rental LED Display Panel , Energy Saving LED Display Advertisement
-
P6 Rental LED Display Indoor , Die Casting Aluminum Cabinets
Product Details
| Brand Name | TeehoLED | Place of Origin | China | |
| Model Number | CE, 3C , RoHS, ISO,FCC,UL |
Product Description
Certification:CE,UL, ROHS, 3C, ISO,FCC
Quick Detail:
Light weight & super slim Quickly and easily installed High refresh rate Beautiful surface designFull?Color?1R1G1B?3-IN-1?SMD?Indoor?Rental?Led?Screen?For?Television?Relay,8S Die Casting Aluminum P5 indoor rental display, 8S P5 Indoor Rental LED Display With Die Casting Aluminum Cabinet
Description:
1. Ultra thin and slim design
2. HD video with vivid pictures
3. Hanging beam structural design makes it easy and fast for installation
4. locks on both sides of cabinet contribute to uniformity and flatness of two neighboring cabinets.
5. Neat and Hidden Wiring allow the led display more tidy and beautiful.
Applications:?
????????????? Stage Background ?
?????????????? Airport & Station
?????????????? Television Relay
?????????????? Information Display?
?????????????? Stadium
?????????????? Event Show
Specifications:
|
Part Number |
Teeho-P5－8S |
|
Resolution |
32(H)×32(V) |
|
Pixel Pitch |
5mm |
|
LED Configuration |
1R1G1B 3-IN-1 SMD |
|
Pixel Density |
40,000 pixels/ ㎡ |
|
Module Size |
160mm*160mm |
|
Cabinet size |
640x 640x7mm |
|
Driving IC |
MBI5024 |
|
Driving Method |
1/8 Scan, Constant Current |
|
Cabinet Weight |
8kg/sq.m. |
|
Mechanical Ratings |
|
|
Hanging Weight Support |
2T |
|
Surface Flatness |
Gap<0.5mm |
|
Optical Ratings |
|
|
Brightness |
1,800cd/ m2 |
|
View Angle |
150°/150° |
|
Gray Scale |
8bits input, correction with 14bits |
|
Display COLOR |
16.7M |
|
Brightness Adjustment |
0～100% |
|
Power Supply |
|
|
Operation Power |
90～260V 50～60Hz |
|
Max. Power Consumption |
850W/ ㎡ |
|
Average Power Consumption |
280W/ ㎡ |
|
Control System |
|
|
Control Mode |
Synchronous display with control PC by DVI |
|
Frame Update Frequency |
60～85Hz |
|
Screen Refresh Frequency |
300～1000Hz |
|
Gamma Correction |
-5.0～+5.0 |
|
Support Input |
Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
|
Control Distance |
Ethernet cable<120m or Fiber Optic<10Km |
|
Brightness Correction |
Pixel, Module, Cabinet |
|
Environmental |
|
|
Operating Temperature |
-30°～+60° |
|
Operating Humidity |
10～95% RH |
|
Operating Life |
