Business Establishment Stadium LED Display
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
Brand Name | Xiwan | Place of Origin | China | |
Model Number | BVO-20 |
Product Description
Certification:CE,Rohs
Business Establishment Stadium LED Display
Quick Detail :
Module size(MM) : 200*200 Pixel Pitch(MM) : p20 Pixel combination : 1R1G1B1W Sub-screen function of the software realizes multi-window display of the complete screen and is able to show images, text, clock and game score and broadcast live show.Description:
BVO series ultra low power LED display or LED screen can be installed as the sport display. The main features are:
1. Half spherical soft covers on the top and front surface of display provide safe guarantee to athletes.
2. With the special removable brackets on the back side of the cabinets, the gradient of display screen could be adjusted easily. These cabinets could also be used for hanging mounting and fixed mounting after removing the brackets.
3. High refresh frequency, high grey level, and no dithering while display of videos, can be used for live TV program, and the pixel correction technology is available.
4. Sub-screen function of the software realizes multi-window display of the complete screen and is able to show images, text, clock and game score and broadcast live show.
5. The connection between cabinets and brackets is a fold-and –unfold block and tackle. This is a tight and advanced connection which can keep all cabinets consistent on one level.
6. Good performance in color uniformity, large view angle, high brightness, low fault rate and easy for maintaining.
We have now P10, P12, P16, P20 and P25, you can choose according to your own applications.
Applications:
sports stadiums, live show broadcast , airport station integrated information dissemination, business establishments, and public square ,Advertising media,
Specifications:
Item No. |
BVO-P20 |
Pixel Pitch(MM) |
P20 |
Module resolution |
16*8 |
Module size(MM) |
320*160 |
Pixel combination |
1R1G1B1W |
Pixel density |
2500 pixels/㎡ |
Driving way |
Static |
Cabinet size(MM) |
960*960 |
Cabinet resolution |
48*48 |
Cabinet pixel |
2304 |
The number of modules |
18 |
Cabinet type |
Fixed installation water proof iron box |
Cabinet weight (Kg) |
55 |
Average Power Consumption (W/㎡) |
≤100W/㎡ |
The maximum power(W/㎡) |
≤200W/㎡ |
Brightness (Cd/㎡) |
6500 |
Gray scale |
16bit(4096 levels) |
Refresh rate |
≥800 |
Brightness adjustment |
256 levels |
Frame frequency |
60HZ |
Input voltage |
110~220VAC |
Working temperature |
-20℃~+50℃ |
Work humidity |
10%-90%RH |
Best stadia |
≥12m |
The whole screen perspective |
H:135°;V:55° |
IP rating |
Front:IP65;Back:IP54 |
MTBF(hrs) |
1000 |
Life span(hrs) |
