Product Details
Brand Name | Xiwan | Place of Origin | China | |
Model Number | BVO-20 |
Product Description
Certification:CE,Rohs
Highway High Brightness P20 Outdoor Led Display /screen Static IP65 / 54 with silan/epistar
Quick Detail:
Cabinet size(MM) :960*960 Cabinet pixel : 2304 Module resolution : 16*8 BVO-12 outdoor full color LED display/LED screen is suitable for commercial and advertising display with advantages of less power consumption, high brightness, High resolution, and long lifetime.Description:
BVO series ultra low power outdoor LED display or LED screen are new products with XIWAN new technology. Xiwan have invested millions of dollars on this new technology. Dedicate to save energy cost for big LED display and improve image quality very effectively. We have now developed P10, P12, P16, P20 and P25, you can choose according to your own applications.
Qualified LED core from Epistars, Silan and other big brand.
Qualified LED driving from Meanwell
Specifications:
Item No. |
BVO-P20 |
Pixel Pitch(MM) |
P20 |
Module resolution |
16*8 |
Module size(MM) |
320*160 |
Pixel combination |
1R1G1B1W |
Pixel density |
2500 pixels/㎡ |
Driving way |
Static |
Cabinet size(MM) |
960*960 |
Cabinet resolution |
48*48 |
Cabinet pixel |
2304 |
The number of modules |
18 |
Cabinet type |
Fixed installation water proof iron box |
Cabinet weight (Kg) |
55 |
Average Power Consumption (W/㎡) |
≤100W/㎡ |
The maximum power(W/㎡) |
≤200W/㎡ |
Brightness (Cd/㎡) |
6500 |
Gray scale |
16bit(4096 levels) |
Refresh rate |
≥800 |
Brightness adjustment |
256 levels |
Frame frequency |
60HZ |
Input voltage |
110~220VAC |
Working temperature |
-20℃~+50℃ |
Work humidity |
10%-90%RH |
Best stadia |
≥12m |
The whole screen perspective |
H:135°;V:55° |
IP rating |
Front:IP65;Back:IP54 |
MTBF(hrs) |
1000 |
Life span(hrs) |
100000 |
Competitive Advantage:
5 advantages of our product
●50% energy savings
Up to 50% reduction in energy consumption, in special circumstances, even more than 70%, it reduced the use-cost and greenhouse gas emissions greatly.
Take BVO-20 LED display as example, compared with ordinary products, per square meter can save energy over 160W for 1 h, a 100m2 screen works 24 hours per day, 365 days per year, it can save energy =(160W×100m2×24h×365)/1000 =140,160KW (KWH), reducing greenhouse gas emissions 106,241kg
●30% higher brightness
Increased 30% max brightness, more than 12,000cd of the brightness could provide the best visual effect under the direct sunlight. If your LED display needs working in the daytime, that’s a wise option.
●30% longe
