1R1G1B SMD P6 Indoor Portable LED Signs Panel For Stage , Rental
- 0 Meter / Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
P7.62 Stage Rental LED Display , IP31 Indoor Full Color Led Sign
-
P10mm SMD Outdoor Portable LED Signs Advertising For Stage Rental
-
IP65 P12 Portable LED Signs Outdoor , 1R1G1B LED Rental Display
-
IP65 P20mm Outdoor Portable LED Signs For Commercial Advertising
-
P16 Outdoor Portable LED Signs Full Color With High Contrast Ratio
-
Rental P4 Portable LED Signs , SMD High Definition LED Display
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | NS-IR-DS-P6 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. High Resolution
2. Excellent Performance & High Reliability
3. 2 years warranty?
4. Front and Rear Access Service for Options
5. Free onsite installation consulting
1R1G1B?SMD?P6?Indoor?Portable?LED?Signs?Panel?For?Stage?,?Rental
Description:
1. High Resolution
27777 dots per ㎡. ?
2. ?Excellent Performance
High refresh rate and enough brightness make the LED display be capable to show all kinds of HD video, images vividly.
3.?2 years warranty
Free replacement and maintenance for spare parts is offered within warranty period. Permanent maintenance service is offered before product’s life expires.
4. Front or Rear access Service Available
Our many outdoor screens have been used by our clients around the world for 3-5 years and no product issues are called.
Applications:
Comprehensive purposes like Cinema, Theatre, trade show, Bar etc.
Specifications:
1. Indoor LED Display Module
|
Module Size (W*H) |
192mm*96mm |
Pixel Configuration |
1R1G1B |
|
Pixel Pitch |
6mm |
Resolution (W*H) |
32dots*16 dots |
|
Pixel Density |
27777 dots/㎡ |
LED Type |
SMD |
2. Indoor LED Display Cabinet
|
Cabinet Size (W*H) |
960mm*768mm |
Module Qty |
40 pcs |
|
? Cabinet Resolution (W*H) |
160 dots*128 dots |
Cabinet Pixel |
20480 |
|
Weight |
40kg/ Cabinet |
Area |
0.737㎡ |
|
Average Power Consumption |
600w/㎡ |
Max Consumption |
1300W/m2 |
3. Methods for Quality Assurance
a. Aging
b. Waterproof test
4. Indoor LED Display Technical Parameter
|
Model No. |
NS-IR-DS-P6 |
|
Pixel Pitch |
6mm |
|
Module Size |
192mm×96mm |
|
Module Resolution(Pixel) |
32dots×16dots |
|
Pixel Density |
27777dots/m2 |
|
LED Type |
SMD |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
1/8 |
|
Cabinet Size |
960×768×135mm |
|
Cabinet Resolution |
160dots×128dots |
|
Brightness |
≥2000 cd/m2 |
|
Contrast |
≥ 4000:1 |
|
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
|
Best Viewing Distance |
4m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
|
