IP31 P10mm Indoor Curved LED Display Advertising , Lightweight
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Flexible P6 Indoor Curved Led Screens Full Color For Bus Station
-
P6 Indoor Curved LED Display Full Color For Mobile Media Advertising
-
P12 1R1G1B Flexible Curved LED Display Panel , 192mm * 192mm
-
SMD3528 IP31 Outdoor Advertising LED Display Board , 160mm * 160mm
-
High Definition P10 Curved LED Display Outdoor For Stadiums , Studio
-
SMD3528 P10 Curved Led Screen , Club Indoor Full Color LED Display
Product Details
Brand Name | Newstar-LED | Place of Origin | China | |
Model Number | NS-IR-DS-P10 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Made By High Quality Material
2. Curved Design and Good Appearance
3. Flexible and Soft
4. Indoor Usage
IP31?P10?Indoor?Curved?LED?Display?Advertising?,?Lightweight
Description:
1.? It can be curved into different shape to fit convex or concave wall or rugged wall or building, and it can be shaped into column to wrap pillars for animation decoration.
2. Easy to maintain, high resolution, good contrast ratio,lightweight, easy to install. Widely used as the information billboard in Airport, Railway station, and big shopping mall, concert and etc.
?
3. The brightness of indoor LED signs can be adjustable for different environment.
4. We make best design with high cost- efficiency due to different demands and we can offer OEM service as well.
?
Applications:
Commercial advertising, mobile media, night club, entertainment events, business establishments, such as banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, etc;
Specifications:
1, Indoor LED Display Module
Dimensions (w x h) |
320mmx160mm |
Resolution (w x h) |
32 x 16 |
Pixel pitch |
10mm |
Pixel Density |
10000/㎡ |
Pixel Configration |
1R,1G,1B |
SMD3528 |
2, Indoor LED Display Cabinet
Dimensions(w x h x d)(mm) |
960x960 |
Module Quantity |
18 |
Physical Resolution (w x h) |
96 x 96 |
Physical Pixels (total) |
9216 |
Weight/Panel (kgs) |
50 |
Material |
Cold rolled steel |
Average Power/sqm (watts) |
280 |
Max Power/sqm(watts) |
825 |
3, Methods for Quality Assurance
a, Aging
1. 100% fully test
2. Condition: 72 hours with 256 grey level
b, Vibration Testing
Condition: 3-5 mins up and down in 5mm range
4, Indoor LED Display Technical Parameter
Model No. |
NS-IR-DS-P10 |
Pixel Pitch |
10mm |
Module Size |
160mm×160 mm |
Pixel Density |
10000dots/m2 |
LED Type |
SMD 3 in 1 |
Pixel Configuration |
1R1G1B |
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
Drive Mode |
Dynamic 1/4 Duty Constant Current |
Cabinet Size |
960×960×135mm |
Cabinet Resolution |
96dots×96dots |
Brightness |
≥1500 cd/m2 |
Contrast |
≥ 2000:1 |
Viewing Angle |
140°(Horizontal )/140°(Vertical ) |
Best Viewing Distance |
8m |
Grey Scale |
10bits/1024levels |
