P16 Full Color Outdoor Advertising Led Display , Wide Angle Display
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Resolution Outdoor Advertising LED Display , P10mm Outdoor Led Screen
-
P10 SMD Round Outdoor Advertising LED Display For Duke Mansion
-
P12 Full Color Outdoor Advertising LED Display Panel , >6000cd/
-
Flexible P8 Indoor Full Color LED Display Screen For Stadiums , Studio
-
P10 Indoor Full Color LED Display , SMD3528 Advertising Led Screen
-
1R1G1B 3 IN 1 P6 Indoor Full Color LED Display , High Resolution
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | NS-OR-DD-P16 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Super brightness: >8000cd/㎡,
2. Support any format of video,
3. Perfect vivid image
4. CE, RoHS qualified.
P16?Full?Color?Outdoor?Advertising?Led?Display?,?Wide?Angle?Display
Description:
1. High viewing angle: 110°(Horizontal )/45°(Vertical )
2. Special Structure design for water-proof, dust-proof, moisture-proof, and anti-static electric
3. High Contrast
The Contrast is above 2000:1, so the viewer can have a wonderful visual
4. Outstanding consistency in color and brightness, no mosaic effects.
Applications:
Commercial advertising:?Square,?Road side, High way, Airport, Wharf, Hotel, Restaurant etc
Specifications:
1. Outdoor LED Display Module
|
Module Size (W*H) |
256mm*256mm |
Pixel Configuration |
1R1G1B |
|
Pixel Pitch |
16mm |
Resolution (W*H) |
16 dots*16 dots |
|
Pixel Density |
3906 dots/㎡ |
LED Type |
3mm Oval Lamp |
2. Outdoor LED Display Cabinet
|
Cabinet Size (W*H) |
1024mm*768mm |
Module Qty |
12 pcs |
|
? Cabinet Resolution (W*H) |
96 dots*64 dots |
Cabinet Pixel |
6144 |
|
Weight |
40 kg/ Cabinet |
Area |
0.6144㎡ |
|
Average Power Consumption |
350w/㎡ |
Max Consumption |
1000W/m2 |
3. Methods for Quality Assurance
a. Aging
b. Vibration Testing
4. Outdoor LED Display Technical Parameter
|
Model???????? No. |
NS-OR-DD-P16 |
|
Pixel Pitch? |
16mm |
|
Module Size |
256mm×256mm |
|
Module Resolution(dots) |
16*16 |
|
Panel Size |
1024mm×768mm |
|
Panel Resolution(dots) |
64×48 |
|
Pixel Configuration(RGB) |
1R1G1B |
|
Pixel Density(dots/m2) |
3906 |
|
Brightness(cd/m2) |
≥ 8000 |
|
Best Viewing Distance(m) |
15-300 |
|
Max. Power Consumption(W/m2) |
1000 |
|
Drive? Mode |
Static |
|
Wavelength |
R? 620-625? G 520-525 B 470-475 |
|
Viewing??? Angle |
110°(H)/45°(V)? |
|
Operating?? Temperature |
–20~60°C? |
|
Video Frame Rate(Hz) |
≥60HZ |
|
Display? Refresh Rate(Hz) |
≥300HZ |
|
Grey? Level(colors) |
16.7million |
|
Life Span |
≥100,000 hours |
|
Working Voltage |
