High Brightness P10 Outdoor Full Color Led Display , 6000cd/Sqm
- T/T L/C D/P D/A
- 7 days
You May Like
-
SMD P5 Portable LED Signs , 1R1G1B Indoor Rental LED Screen
-
P10 Commercial Portable LED Signs Indoor For Theatre , Trade Show
-
1R1G1B SMD P6 Indoor Portable LED Signs Panel For Stage , Rental
-
P7.62 Stage Rental LED Display , IP31 Indoor Full Color Led Sign
-
P10mm SMD Outdoor Portable LED Signs Advertising For Stage Rental
-
IP65 P12 Portable LED Signs Outdoor , 1R1G1B LED Rental Display
Product Details
Brand Name | Newstar-LED | Place of Origin | China | |
Model Number | NS-OR-DD-P10 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. High Brightness more than 6000cd/sqm
2. Rental and events usage
3. Portable
4. 2 years warranty?
5. Free onsite installation consulting
High?Brightness?P10?Outdoor?Full?Color?Led?Display?,?6000cd/Sqm
Description:
1) High Brightness
More than 7000nits, it delivers enough brightness in outdoor. Even under direct sun light, it performs very well.
?
2) Seamless Design?
It eliminates the gap between the module and cabinet making LED screen much more even.?
3) High Quality and Reliability
Our many outdoor screens have been used by our clients around the world for 3-5 years and rarely product issues are called.
4) High definition
High definition and delivers vivid and clear pictures
5) High Contrast Ratio
Newstar outdoor LED screens enable to deliver sharp visual effects to our audience.
Applications:
Ideal for dazzling different events, such as Stage, Concert, Fashion Show, Wedding, Conference, Building,?Hotel, Club & Bars, Festival, etc.
Specifications:
1. Outdoor LED Display Module
Module Size (W*H) |
160mm*160mm |
Pixel Configuration |
1R1G1B |
Pixel Pitch |
10mm |
Resolution (W*H) |
16 dots*16 dots |
Pixel Density |
10000 dots/㎡ |
LED Type |
3mm Oval Lamp |
2. Outdoor LED Display Cabinet
Cabinet Size (W*H) |
960mm*640mm |
Module Qty |
24 pcs |
Cabinet Resolution (W*H) |
96 dots*64 dots |
Cabinet Pixel |
6144 |
Weight |
50 kg/ Cabinet |
Area |
0.6144㎡ |
Average Power Consumption |
300w/㎡ |
Max Consumption |
1000 W/m2 |
3. Methods for Quality Assurance
a. Aging
1. 100% fully test
2. Condition: 72 hours with 256 grey level
b. Vibration Testing
Condition: 3-5 mins up and down in 5mm range
4. Outdoor LED Display Technical Parameter
Model No. |
NS-OR-DD-P10 |
Pixel Pitch |
10mm |
Module Size |
160mm*160mm |
Module Resolution (W*H) |
16 dots*16 dots |
Pixel Density |
10000 dots/ ㎡ |
LED Type |
3mm Oval Lamp |
Pixel Configuration |
1R1G1B |
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
Drive Mode |
Dynamic 1/4 Duty Constant Current |
Cabinet Size |
960×640×150mm |
Cabinet Resolution |
96dots×64dots |
Brightness |
≥6000cd/㎡ |
Contrast |
≥2000:1 |
Viewing Angle |
110°(Horizontal )/45°(Vertical ) |
Best Viewing Distance |
10m-300m |
