Stubborn P20mm Outdoor Advertising LED Display , High Brightness
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
DIP P20 Full Color Outdoor Advertising Led Display Billboard
-
P16 Full Color Outdoor Advertising Led Display , Wide Angle Display
-
High Resolution Outdoor Advertising LED Display , P10mm Outdoor Led Screen
-
P10 SMD Round Outdoor Advertising LED Display For Duke Mansion
-
P12 Full Color Outdoor Advertising LED Display Panel , >6000cd/
-
Flexible P8 Indoor Full Color LED Display Screen For Stadiums , Studio
Product Details
| Brand Name | Newstar-LED | Place of Origin | China | |
| Model Number | NS-OR-DD-P20 |
Product Description
Certification:CE, RoHS, UL, FCC, ISO
Quick Detail:
1. Front Side IP65, Back Side IP54
2. Stubborn structure design
3. CE & RoHS Certified ?
4. 2 years warranty, FREE maintenance service.
Stubborn?P20?Outdoor?Advertising?LED?Display?,?High?Brightness
Description:
1. High Quality and Reliability
Our many outdoor screens have been used by our clients around the world for 3-5 years and rarely product issues are called.
2. Waterproof and 2 Year Warranty
Water Proof IP65 and 2 year warranty. LED display can work in all-weather condition very well. CE & Rohs approved
3. High Brightness
More than 6500nits. Audience can view from a far distance.
?
Applications:
Stadium inside and outside such as football pitch, baseball, basketball etc
Specifications:
1. Outdoor LED Display Module
|
Module Size (W*H) |
320mm*160mm |
Pixel Configuration |
1R1G1B |
|
Pixel Pitch |
20mm |
Resolution (W*H) |
16 dots*8 dots |
|
Pixel Density |
2500 dots/㎡ |
LED Type |
DIP |
2. Outdoor LED Display Cabinet
|
Cabinet Size (W*H) |
1280mm*960mm |
Module Qty |
18 pcs |
|
? Cabinet Resolution (W*H) |
96 dots*48 dots |
Cabinet Pixel |
4608 |
|
Weight |
60kg/ Cabinet |
Area |
1.23㎡ |
|
Average Power Consumption |
350w/㎡ |
Max Consumption |
1000W/m2 |
3. Methods for Quality Assurance
? ?a. Aging
b. Waterproof test
4. DIP Outdoor LED Display Technical Parameter
|
Model No. |
NS-IR-DS-P20 |
|
Pixel Pitch |
20mm |
|
Module Size |
320mm×160 mm |
|
Module Resolution(Pixel) |
16dots×8dots |
|
Pixel Density |
2500dots/m2 |
|
LED Type |
DIP |
|
Pixel Configuration |
1R1G1B |
|
Wavelength (R.G.B) |
R:625±2nm G:525±2nm B:470±2nm |
|
Drive Mode |
Static |
|
Cabinet Size |
1280×960×135mm |
|
Cabinet Resolution |
96dots×48dots |
|
Brightness |
≥6500 cd/m2 |
|
Contrast |
≥ 4000:1 |
|
Viewing Angle |
110°(Horizontal )/45°(Vertical ) |
|
Best Viewing Distance |
15m |
|
Grey Scale |
10bits/1024levels |
|
Color Capability |
16777216 |
|
Color Temperature |
5000-9300K |
|
Maximum Power Consumption |
1000W/m2 |
|
|
