Plastic Injection Molding Oil Temperature Control Unit with 320 Degree , CE / ISO

Brand Name	AODE		Place of Origin	China
Model Number	AGBT-300-60

Delivery Time:Within 20days after receiving deposit
Certification:CE|ISO

Plastic Injection Molding Oil Temperature Control Unit with 320 Degree , CE / ISO

Quick Detail:

1.safe and reliable

2. High temperature and low pressure

3. Furnace with double row pipe

4. Brand Name:AODE

5. Certification:CE & ISO

6. Head:72m

7. Maximum working temperature: 320℃

Description:

Save energy, low running costs, do not need complex water treatment equipment, save water resource, can alternative water heating boiler in water resource sub-shortage areas. Precise temperature control: stable heating, precise temperature adjustment, automation. High thermal efficiency: closed-cycle heating, no waste heat emission, load adaptability, can maintain optimum thermal efficiency under different conditions, high integrated thermal utilization efficiency. Safe and reliable: complete operating control and safety monitoring device. Heating system runs opening, high safety factor. High-temp and low pressure: can obtain a higher working temperature under lower operating pressure. Well-known international brand burners and advanced automatic control system, the boiler combustion more stable, operation more convenient, safe and reliable. Furnace with double row pipe, heating surface is sufficient to reduce the heat load of the pipe surface, the heat-conducting oil use safe. Reasonable medium flow, thermal oil from the low (inlet) to high (outlet), generated gas can not stay in the furnace, the system can be easily discharged it. The furnace size is matched with the burning flame, positive pressure combustion increase the radiation heat transfer efficiency

Specifications:

ITEM	UNIT	AGBT-300-60
Rated thermal power	KW	700
Thermal efficiency	%	85
Design pressure	Mpa	0.6
Maximum working temperature	℃	320
Oil volume within the furnace	M3	0.5
Circulating oil	M3/h	60
Head	m	72
Piping nozzle caliber	mm	100
System installed capacity	KW	30
Size	L(mm)	3450
	W(mm)	1980
	H(mm)	2080?

Competitive Advantage:

1. Strict quality control system

2. Three factories in shenzhen, tianjin and suzhou. More than 60 offices in China.

3. Our product is environmental and energy-saving

4. We have the production certification organic heat transfer material heater

5. High density heat insulation cotton and aluminum foil

6. Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST

7. Imported microcomputer or PLC

8. Customization thick copper pipe 1.0-1.2

Applications:

Chemical Industry

Hot Rolling Machine: Calender Rolls, Wood Presses, Laminating Presses,Molding Presses, Rubber Presses, Jacketed Vessels, Reactors, Heat Exchangers, Mixers, Printing Machines, Asphalt, Vulcanizing Presses.
Die casting,plastic? Injection molding, light guide plates, connectors, Chemical engineering, Shoe materials, Pringting and dyeing, Drying and banburying.

Nowadays, Aode Machinery Co.,ltd continue to uphold the purpose of international standards designs and high quality products, applying ourselves to providing high standard produc
