PLC Water Type Mold Temperature Control Unit with Quick Heating and Cooling

Brand Name	AODE		Place of Origin	China
Model Number	GWS-800

Delivery Time:Within 20days after receiving deposit
Certification:CE|ISO

PLC Water Type Mold Temperature Control Unit with Quick Heating and Cooling

Quick Detail:

1. Electric power:45-108KW

2. Cool/Hot water circling inlet/outlet diameter:DN25(3/8×10)

3. Chilled water inlet/outlet diameter:1.2inch

4. Certification:CE & ISO

5. Control mode: Computer PLC processor+mak-machine interface touch control

6. Warranty:1 year

Description:

Eliminate soluble wiring, melted marks, and corrugated, silver marks on the product surface. ?Completely solve surface shrinkage of plastic products Improve the surface gloss, the surface roughness is similar to mirror Products do not need to spray paint processing, improve the rate of finished products of 20-30% Solve the fiber products floating fiber problem, make the product quality perfect The thin-wall molding can improve the liquidity of injection, improve product quality and intensity Thick-wall molding can improve the liquidity of injection, improve product quality and intensity Thick-wall injection molding cycle can be reduced by 60%, increase the liquidity and fill effects of the plastic 95% heat energy recovery 100% medium recovery Without connecting boilers and other external thermostat auxiliary equipment, omitted the complex boiler equipment(high-pressure equipment safety and environmental approval) and pipeline project Completely solve the problem of the boiler steam non-recyclable Small volume can match different machines, 180℃ hot water can replace the boiler, which is not environmental friendly 10.4-inch LCD true color LCD display(optional), touch Chinese digital input, Chinese interface, simple operation Full closed-loop system to control the input and output the detection temperature, mold temperature feedback to PLC, number and color changes display, to ensure output accurate and stable All components are imported from Europe and America One/Two-way mold temperature detection(optional), stainless steel input and output pipes, multiple sets of input and output interfaces Machine equipped with: heating, cooling, hot and cold transformation functions High-temperature hot water, cooling water recycling system, energy saving effect is obvious

Specifications:

ITEM	UNIT	GWS-800
Power supply	V	3∮/380V/50HZ
Power	KW	114
Control mode		Computer PLC processor + man-machine interface touch control
Electric power	KW	45-108
Heating pump power	KW	2.8
Cooling pump power	KW	2.2
Cool/Hot water circling inlet/outlet diameter	Inch	DN25(3/8×10)
Chilled water inlet/outlet diameter	Inch	1.2
Size	mm	1700×850×1400
Weight	KG	700

Competitive Advantage:

1. Strict quality control system

2. Three factories in shenzhen, tianjin and suzhou. More than 60 offices in China.

3. Our product is environmental and energy-saving

4. We have the production certification organic heat transfer material heater

5. High density heat insulation cotton and aluminum foil

6. Electric appliances brands:OMRON, JUJI, TE.LG, MOLLER, ABB and WEST

7. Imported microcomputer or PLC

8. Customization thick copper pipe 1.0-1.2

Applications:

Chemical Industry

Hot Rolling Machine: Calender Rolls, Wood Presses, Laminating Presses,Molding Presses, Rubber Presses, Jacketed Vessels, R
