Automatic Electric Steam Generator 16kw 3 phase with waterproof control system

Brand Name	KSA		Place of Origin	China
Model Number	KSA-E160

Delivery Time:1-3 workdays
Certification:CE

waterproof control system stainless steel steam generators 16.0kw/400v/3phase with auto drain function for home and commercial use??

Quick Detail:

Type: Wet Steam Sauna control panel: digital Power output: 16.0kw voltage: 380V~400V Main Material: stainless steel tank, galvanizing and powder coated shell Color: grey green Current: 23.5A phase: 3 Auto protection: over-heat protect, boil dry protect, pressure balancing valve, leakage protect, lack of water protect and the others Auto function: auto water inlet , auto drain, auto flushing, auto power off Shape: Cuboid Size: 475*185*450mm Room volume(cubic meter): 14~19 Usage: steam sauna room working time: 1~60 minutes or long time Heating: heat elements Power source: Electric Time Setting: 1-60mins Temperature range to control: 95 F degree~131 F degree Temperature range to show on control panel: 43 F degree ~140 F degree Exclusive microprocessor operating system Precision temperature probe for optimal steamroom temperature control Removable and serviceable industrial strength heating elements We produce steam generator over 10years! Intelligent to heat by segment, fill water with steam, automatic to turn off, a self flushing cycle ,with pressure to drain. Intelligent to indicate fault with the code. To show CH can working for long Can pause at working Light can be connected to controller, water inflow to magnetize and filtrate etc. Intelligent to save two sets of temperature, can individual set time by memory

Automatic Sauna Steam Generator 16kw 3 phase with waterproof control system

Description:

“Save Worry Save Trouble”!

This series is born in 2008. After years of test, it is steady performance.

You don’t need to spend a lot of time to solve the problems like a new product.

This KSA-E series steam generator is our featured products.

1.?Fast steam: With the special and delicate design of the system, a large volume of steam will come out within 5 minutes after the heating elements begin to work, and quickly boosts the temperature to the setting value. The intelligent heating-by-section makes heating process more efficient and minimizes the energy used, more importantly, non-stop steam generation is ensured even during the water tank filling period.

2. ?Multi-protection. Besides the GFCI (Ground Fault Circuit Interrupter ), the KSA-E series also installed the following protection circuits: over-heat protection; lack-of-water protection; over-pressure protection, assisted by the newest microprocessor technology to give automatic diagnose message in order to give customer maximum level of safety and easy trouble-shooting when any fault happens.

3.?As professional we could tell you that the decisive fact for a steam generator is actually the quality of the heating elements rather than functions. Therefore we choose the best magnesian powder, 304# stainless steel, and seal glue to guarantee a durable product. We also oxidize the heating elements surface with Teflon . More importantly, the advanced automatic washing, cooling and draining functions minimize the conglomeration of calcium and magnesium on the heating element so as to greatly extend the life of heating elements.

4.?To install water magnetizing filter impurity, or pressure reducer to reduce the inlet water pressure, or external light according to customer requirements.? ?

Applications:

Fit for home use and commercial use

Make you more healthy!

Specifications:

1) Power:160kW, voltage: 220/380V, phase:3
2) controllers: KSA-elegance
3) Operates machine for 1~60 minutes before turning off
4) Automatically shuts down when water level is too low
5) Temperature high limit switch
6) With cleaning and draining function
7) High quality with 2-year warranty

Please see the details for your installment reference:

Model	Power KW	Room volume (m3)	Power requirements?????????? 50/60Hz	Current?(A)	Power??????? wire (Copper)????????? N*mm2	Dimensions ?CM	Packing dimensions CM	Gross weight kg
KSA-E160	16.0	13~18	380
