Single Output CCTV Power Supplies , Battery Back up Power Supply

Model

12VDC10A1P/B

Power

120W

Metal Case Dimension

37.7×33.2×8.2cm

Net Weight

3.45kgs

Input

Input Voltage

110/220VVAC

Input Voltage Frequency

50Hz-60Hz

Output

Output Voltage

12VDC±5%

Output Current

10A

Output Ripple Noise(Vp-p)

110mVp-p@25℃/

Rated input voltage & Rated output load

Reply Time of Starting up

≤3S? Input 100Vac, Rated output load

Fuse

Type /Rating

PTC? 1.6A/60V

Protection

Over Current Protection

Over current point 10～11A?

Short-circuit Protection

When short-circuit occurs, the individual PTC fuse will break the circuit. When the fault is cleared, it will switch back to normal automatically.

Charge

The power supply will automatically switch to storage battery if there is outage.

Circumstances

Working Temperature

0℃-+50℃

Storage Temperature

-20℃-+80℃

RH

20%-90%

Heat Release

Natural heat dissipation

Connection

Input

Three-pin socket

Output

1 channel output

Dielectric Strength

Input to output

1500Vac/60S? leakage current≤1.5mA

Input to FG

1500Vac/60S? leakage current≤2.0mA

FG to output

500Vac/60S?? leakage current≤1.5mA

Insulating strength

Input to output

≥20MΩ/500VDC@25℃

Leakage Current

≤0.02mA @AC110V(220V)/25℃

RG

≤0.012Ω@DC8V/25A/25℃
