WEXP - 85 Thermal - Conductive Insulation White, Blue, Black Epoxy Resin With Low Adhesive
- T/T L/C D/P D/A
- 7 days
You May Like
-
Anti - Alkaline, Waterproof Anti - Pressing Black Epoxy Resin With Electric Strength
-
Low Adhesive Anti - Pressing Curable Dust - Proof Black Epoxy Resin With Two Part
-
Double - Component Flame - Retardant Dust - Proof Black Epoxy Resin For Electronics
-
Anti - Pressing Hardness Flame - Retardant Brown, Black Epoxy Resin With Low Adhesive
-
Hardness, Waterproof Silvery Grey, Black Epoxy Resin With 8000 - 18000mpa.s Viscosity
-
Double - Component Anti - Pressing Blue, Brown, Black Epoxy Resin With 24h Curing Time
Product Details
| Brand Name | DH | Place of Origin | China | |
| Model Number | WEXP-85 |
Product Description
Certification:ISO9001,ISO14001,GB/T28001
WEXP?-?85?Thermal?-?Conductive?Insulation?White,?Blue,?Black?Epoxy?Resin?With?Low?Adhesive
Description:
WEXP-85 is a double-component black curable thermal-conductive & flame-retardant Epoxy Encapsulating, with low adhesive and excellent flow and it can penetrate into the gap of products; it can be solidified through normal temperature or heating with suitable speed of solidification; there is no bubble with plain and glazing surface and high hardness; the solidified materials have an excellent performance of anti-alkaline, waterproof, oil- proof and dust-proof, which is humid and thermal resistant and air aging; it owns excellent electric and physical features of insulation, anti-pressing and high degree of adhesive.
Specifications:
Using?of?Technology:?
1.?Curing?Condition?(Formula-1):
Normal?Temperature?24Hours,Or?60°C/2Hours
2.?Curing?Condition?(Formula-2):
80°C/2Hours?+?100°C/2Hours+?120°C/6Hours
3.?Formula?1:?
WEXP-85:?Hardener(KLH-855)=100g:13g.
4.?Formula?2:?
WEXP-85:?Hardener(Acid?Anhydride?Hardener)=100g:37g.
5.?Operation?Process:
Weight?to?accord?the?mixture?ration,?well?stirred,?vacuum?deforming,?and?then?packing.
Performance?after?curing?:
|
Item |
Formula?1 |
Formula?2 |
|
|
Volume?Resistance |
Ω-cm |
>1014 |
>1014 |
|
Surface?Resistivity |
Ω |
>1013 |
>1013 |
|
Martin?Heat?Resistance |
°C |
>75 |
>75 |
|
Electric?Strength |
kV/mm |
>20 |
>20 |
|
Dielectric?Constant |
- |
3-5 |
3-5 |
|
Dissipation?Factor |
- |
<0.03 |
<0.03 |
|
Rockwell?hardness |
- |
>75 |
>75 |
|
Impact?Strength |
kJ/m2 |
>7 |
>7 |
|
Bending?Strength |
MPa |
>80 |
>60 |
|
Absorption?Capacity |
% |
<0.05 |
<0.05 |
|
Flame?Resistance |
Level |
UL-94-V-O |
UL-94-V-O |
|
Oxygen?Index |
- |
>30 |
>30 |
Product?Technical?Specification:?
|
Appearance |
- |
Black,?White,?Blue,Brown?,Silvery?Grey,?Options |
|
Viscosity(25°C) |
mPa.s |
8000-18000 |
|
Density(25°C) |
g/cm3 |
1.20-1.90 |
|
Curing?time |
h |
<24 |
