138MPa Bending Strength Casting Epoxy Resin System For High Voltage Winding Under Vacuum
- T/T L/C D/P D/A
- 7 days
You May Like
-
Crafts Adhesive Transparent Brightness Clear Casting Resin For Solar Panel Casting
-
Yellow / Black, Thick, Liquid Bubble Free Casting Epoxy Resin For Dry Type Transformer
-
1.10 - 1.20 Density 7000 - 14000 Viscosity Casting Epoxy Resin With Electric Strength
-
1.10 - 1.20 g / Cm3 Density 3 Colour Casting Epoxy Resin With 7000 - 14000 Mpa.s Viscosity
-
CW - 200 Light Coating Epoxy Self - Levelling Casting Resin System For Indoor Equipment
-
Custom 7000 - 14000 Mpa.s Viscosity Casting Epoxy Resin Vacuum Degassing For 0.5 -1 Hour
Product Details
| Brand Name | DH | Place of Origin | China | |
| Model Number | CW-AF |
Product Description
Certification:ISO9001,ISO14001,GB/T28001
138MPa?Bending?Strength?Casting?Epoxy?Resin?System?For?High?Voltage?Winding?Under?Vacuum
Description:
CW-AF casting resin system is specially designed for casting and blending high voltage winding under vacuum.
Specifications:
|
Material |
Colour |
Viscosity |
Density |
|
mPa.s(25°C) |
g/cm3(25°C) |
||
|
CW-AF?Epoxy?Resin |
<3 |
7,000-14,000 |
1.10-1.20 |
|
CW-905?Hardener |
<6 |
40-200 |
1.15-1.25 |
|
CW-040 Flexibilizer |
<3 |
50-110 |
0.95-1.05 |
|
CW-061 Accelerant |
<3 |
1-15 |
0.85-0.98 |
Formula?Using?Technology:
1.?Blending?Ratio:?
|
Material |
Casting?Formula (Weight?Ratio) |
Base?Formula (Weight?Ratio) |
|
CW-AF Epoxy?Resin |
100g |
100g |
|
CW-905 Hardener |
100g |
100g |
|
CW-040 Flexibilizer |
5-25g |
9g |
|
CW-061 Accelerant |
0.1-2.5g |
0.2g |
According the different requirements, customer can take appropriate readjustment. Weight to batch charging with ratio by selected, mix stirred at 60°C, vacuum degassing for 0.5-1 hour, than pouring.
3. Curing Condition:(1),100°C/2Hours+120°C/2Hours+130-140°C/10Hours
(2),80°C/2Hours+100°C/1Hours+120°C/8Hours(3),80°C/6Hours+120°C/8Hours
Cured PerformanceItem
| ? |
Test?Value |
||
|
Absorption?Capacity(23°C×24h) |
% |
0.06 |
|
|
Impact?Strength |
kJ/m2 |
18 |
|
|
Bending?Strength |
MPa |
138 |
|
|
Bending?Modulus |
MPa |
3150 |
|
|
Distortion?Temperature |
°C |
85 |
|
|
Electric?Strength |
MV/m |
30.3 |
|
|
Arc?Resistance |
s |
72 |
|
|
Dissipation?Factor |
(RT) |
- |
0.0054 |
|
(100°C) |
- |
0.0049 |
|
|
Dielectric?Constan |
