Home > Products > Casting Epoxy Resin > CW - AF138MPa Bending Strength Casting Epoxy Resin With 30.3 MV / M Electric Strength
CW - AF138MPa Bending Strength Casting Epoxy Resin With 30.3 MV / M Electric Strength
- T/T L/C D/P D/A
- 7 days
You May Like
-
9000 - 17000 Viscosity Light Yellow Transparent Liquid Casting Epoxy Resin With CW - 6225
-
Thermal - Conductive Fast Curing Dust - Proof Casting Epoxy Resin With Low Viscosity
-
Black, White Thermal - Conductive Two Component Casting Epoxy Resin With Low Adhesive
-
Pale Yellow Transparent Liquid Low Viscosity Battery Sealant With 2 : 1 Mixing Ratio
-
Transparent, Tenacity, Light Colour Battery Sealant For Bonding, Sealing Battery Cases
-
Smooth, Free Bubbles, Bright Colour Low Viscosity Battery Sealant With 2:1 Mixing Ratio
Product Details
| Brand Name | DH | Place of Origin | China | |
| Model Number | CW-AF |
Product Description
Certification:ISO9001,ISO14001,GB/T28001
CW?-?AF138MPa?Bending?Strength?Casting?Epoxy?Resin?With?30.3?MV?/?M?Electric?Strength
Specifications:
|
Material |
Colour |
Viscosity |
Density |
|
mPa.s(25°C) |
g/cm3(25°C) |
||
|
CW-AF?Epoxy?Resin |
<3 |
7,000-14,000 |
1.10-1.20 |
|
CW-905?Hardener |
<6 |
40-200 |
1.15-1.25 |
|
CW-040 Flexibilizer |
<3 |
50-110 |
0.95-1.05 |
|
CW-061 Accelerant |
<3 |
1-15 |
0.85-0.98 |
Formula?Using?Technology:
1.?Blending?Ratio:?
|
Material |
Casting?Formula (Weight?Ratio) |
Base?Formula (Weight?Ratio) |
|
CW-AF Epoxy?Resin |
100g |
100g |
|
CW-905 Hardener |
100g |
100g |
|
CW-040 Flexibilizer |
5-25g |
9g |
|
CW-061 Accelerant |
0.1-2.5g |
0.2g |
According the different requirements, customer can take appropriate readjustment. Weight to batch charging with ratio by selected, mix stirred at 60°C, vacuum degassing for 0.5-1 hour, than pouring.
3. Curing Condition:(1),100°C/2Hours+120°C/2Hours+130-140°C/10Hours
(2),80°C/2Hours+100°C/1Hours+120°C/8Hours(3),80°C/6Hours+120°C/8Hours
Cured PerformanceItem
| ? |
Test?Value |
||
|
Absorption?Capacity(23°C×24h) |
% |
0.06 |
|
|
Impact?Strength |
kJ/m2 |
18 |
|
|
Bending?Strength |
MPa |
138 |
|
|
Bending?Modulus |
MPa |
3150 |
|
|
Distortion?Temperature |
°C |
85 |
|
|
Electric?Strength |
MV/m |
30.3 |
|
|
Arc?Resistance |
s |
72 |
|
|
Dissipation?Factor |
(RT) |
- |
0.0054 |
|
(100°C) |
- |
0.0049 |
|
|
Dielectric?Constant |
(RT) |
- |
3.3 |
