HP-650IR-X CCTV Camera, Waterproof IR Camera, Color CCD Camera

Function

?color ccd camera

Imaging Sensor

1 / 3\" SONY EXVIEW HAD CCD

Pixel

PAL:752(H)×582(V);

NTSC:768(H)×494(V)

Signal System

PAL/ NTSC

Syn. System

Internal Synchronization

Shutter speed

PAL:1/50~1/100000s;

NTSC:1/60~1/100000s

S/N Ratio

More than 50dB(AGC OFF)

Video Output

1.0Vp-p, 75 ohms

Horizontal resolution

Color 650TVL, B/W 700TVL

Minimum Illumination

Color0.1Lux(F1.2,50IRE,AGCON)

B/W:0.001Lux(F1.2,50IRE,AGC ON)

D/N Switch

Auto/Color/B/W/External Control

Brightness Switch

Color to B/W & B/W to Color for option

D/N Switching Time

0s~10s

Title setting

16 characters

Title Position

Any position on the Screen

Image Brightness

0~99 adjustable

AGC

Off/12db/24db/36db

OSD

English/Chinese OSD

Peripheral Brightness Compensation

0~50 adjustable

Strong Light Reversion

0~60 adjustable

Backlight Compensation

0~3 adjustable

PRIVACY

1~8 Zones

Privacy Zone Color

Color 0~Color 7 optional

ATR

Off/On/Auto

Noise Reduction

2D-DNR

Motion Detection

On / Off (multi-sensitivity settings, alarm time optional)

AWB

ATW/PUSH/USER1/USER2/ANTI CR/MANUAL/PUSH LOCK

Special

Rotation/ up-side down /Mirror/Off

Sharpness

On/off(Level Adjustable)

GAMMA

0.3~1.0 adjustable

CCD white Point Auto-detection

Support

Auto-completion point

White and black points automatically added

RS-485 Remote control Optional

Support

Communication Add.

1-254 optional

BPS baud rate

2400/9600/14400/19200/38400

Control Protocol Optional

Pelco-D

Video Output

BNC method

Power Supply

DC12V/AC24V(optional)

Power consumption

2.0 W

Operation Temperature

-100C~+500C
