Routing, Punching HAL Lead - Free 0.6 - 3.2mm Thickness Multi-Layer PCB For Computers

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Winnal		Place of Origin	China
Model Number	CE, ROHS, UL

Delivery Time:5-15 days

Routing,?Punching?HAL?Lead?-?Free?0.6?-?3.2mm?Thickness?Multi-Layer?PCB?For?Computers

Description:

Specifications:

Product?Technical?Parameter
Basic?technology	Parameter
Single/Double?sided	Multilayer
Number?of?Layers	1-2	4~16
Copper?Thickness	0.25~3.0OZ	0.5~3.0OZ
Base?Board?Thickness	0.2~3.2mm	0.6~3.2mm
Incombustibility	94V-0	94V-0
Peelable?resistance	12.3N/cm	12.3N/cm
Twist?	≤0.5%	≤0.5%
Insulation?resistance	≥1011Ω	≥1011Ω
Test?voltage	10-300V	10-300V
Finished?board?area	560×970mm	560×970mm
Min.?Line?Width?and?Spacing	0.1/0.1mm	0.1/0.1mm
Copper?thickness?in?hole	≥25.0um	≥25.0um
Mini.?pad?diameter	Inner?layer		0.05mm
Out?layer	0.076mm	0.076mm
Mini.?Hole?Diameter	0.25mm	0.20mm
Hole?tolerance	PTH	±0.076mm	±0.076mm
NPTH	±0.05mm	±0.05mm
Hole?location?tolerance	±0.076mm	±0.05mm
profile?tolerance	Routing	±0.1mm	±0.1mm
Punching	±0.13mm	±0.13mm
Solder?mask?bridge?ability	≥0.1mm	≥0.075mm
Solder?mask?rigidity	6H	6H
Solderable?test	245℃?????5?second	245℃?????5?second
