Medium Range 30 - 80CM Intelligent Car Parking System for Residential Community IP65 60Hz

Medium Range 30 - 80CM Intelligent Car Parking System for Residential Community IP65 60Hz

Barriers:

Dimensions: 330 x 330 x 1, 000mm

Arm material: aluminum-alloy

Housing material: 1.8mm cold-rolled steel

Voltage: 220V-240V

Motor voltage: AC 20V

Protection grade: IP65

Rail up or down time: 4 to 6 seconds

Transmission sine linkage

Boom type: straight or foldable (optional)

Rated power: 80W

Boom length: 3-6meters

Frequency: 50 to 60Hz

Boom dimensions (W x H): 45 x 100mm

Working temperature: -45 to 80 centigrade degree

Boom weight: 5.5kg

Operating humidity: no less than 90%

Operating life: 500 million

Net weight: 49kg

Gross weight: 55kg

Entrance equipment:

Automatic barrier (straight-arm or foldable-arm) for entry and exit

Vehicle sensor and cable

Controller for entry and exit

Control board

Medium range ID reader (30-80cm)

Transformer power (optional)

Medium range ID card register

Management software and software dog

Communication shift

Medium range ID card

The main engine of villa inter con system (optional)

Applications:

residential community, office building, factory, hosipital, government building etc.

Descrition:

It is designed for registered parkers only, he swipes his registered proximity card onto entry controllers, the entry barrier will automatically open and he enters. When he leaves, the same will happen at exit.

there is external medium range RFID reader instead of built-in proximity reader on entry controllers, entry barrier will automatically open and he enter w/o stop if the tag is read by medium range RFID reader. The same will happen at exit. It is ideal solution for parking lots with medium-low traffic flow such as residential community, office building, factory, government building etc.
