Short Range Parking Barrier Systems with Temporary Card Dispenser Payment Function IP65

Short Range Parking Barrier Systems with Temporary Card Dispenser Payment Function IP65

Barriers:

Dimensions: 330 x 330 x 1, 000mm

Arm material: aluminum-alloy

Housing material: 1.8mm cold-rolled steel

Voltage: 220V-240V

Motor voltage: AC 20V

Protection grade: IP65

Rail up or down time: 4 to 6 seconds

Transmission sine linkage

Boom type: straight or foldable (optional)

Rated power: 80W

Boom length: 3-6meters

Frequency: 50 to 60Hz

Boom dimensions (W x H): 45 x 100mm

Working temperature: -45 to 80 centigrade degree

Boom weight: 5.5kg

Operating humidity: no less than 90%

Operating life: 500 million

Net weight: 49kg

Gross weight: 55kg

Entrance equipment:

Automatic barrier (straight-arm or foldable-arm) for entry and exit

Vehicle sensor and cable

Controller for entry and exit

Control board

ID reader

Temporary Card dispenser

LED graphic display on the controller

Voices prompt (optional)

Villa inter con system (optional)

Transformer power (optional)

ID card register

Management software and software dog

Communication shift

ID card

The main engine of villa inter con system (optional)

Applications:

residential community, office building, factory, hosipital, government building etc.

Description:

It is a modern series parking management system for managing pay-to-park facilities with high traffic flow, for both occasional and registered parker.

For a hourly parker, when he comes to entry, he himself presses a button to take a proximity card from entry controller, after that the entry barrier automatically opens and he enters, when he comes to exit where a manual-pay-station is installed nearby, he gives his card to the guard, the guard read the card on a card reader, parking amount will be shown on the LED display or computer, then the parker pay cash and then barrier open and he leaves.

For a registered parker, he enters or leaves by card swiping.
