Home > Products > Level Meter > HG-5 Glass Panel Level Meter
HG-5 Glass Panel Level Meter
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
You May Like
Product Details
| Brand Name | Beixing | Place of Origin | China | |
| Model Number | HG-5 |
Product Description
General information:
HG-5 type glass board level meter is widely used for measuring content liquid medium level on many kinds of container.
Features:
Visual reading
Flange connection, easy installation
High pressure resistant
The main technical parameters:1. Mode (center distance L): 500 800 1,100 1,400 1,700 (mm)
Visual reading distance: 260 560 860 1,160 1,460 (mm)
2. Working pressure: 1.6, 2.5, 4.0, 6.3 MPa
3. Medium temperature: 20 ~ 250 ℃
4. Needle valve auto shut pressure: ≥0.3MPa
5. Jacketed tracing steam pressure: ≤0.6MPa
6. Material: I – Carbon steel, II – 1Cr18Ni9Ti, III – Lining
7. Connection type: flange, DN20, HG20592~20635-97, or other flange standard
Producing standard: HG5-1364 ~ 1370-80
