UFZ-55 top loaded floating ball liquid level meter

UFZ-55 top loaded floating ball liquid level meter

General information:

UFZ-55 Top loaded floating ball liquid level meter is used for measuring all kinds liquid level in the containers that not easy to fit side, especially good for the banks underground.

The main technology parameters:

1. The basic type

(1) Measuring range: 500~3000mm

(2) Error: ±10mm

(3) Working pressure: ≤ 1.6MPa

(4) Medium temperature: -40~300

(5) Medium density: ≥0.7g/cm³

(6) Flange connection: DN150,PN1.6,standard HG20592~20593-97(or other     standard)

2. The alarm

(1) Alarm error: ±5mm

(2) Output form: Often a signal switch

(3) Contact capacity: 24V.DC,0.3A

(4) Working life: >10⁵

(5) Power source: 24V.DC

(6) Outlet: M20*1.5(internal thread)

(7) Transmission range: 3km

(8) Working Temperature: -40~60℃

(9) Anti-explosion grade: anti-explosion type and diiBT-D

(10) Degrees of protection provided by enclosure: IP65

(11) Weight: 0.5kg

3. Transmitter

(1) Measuring range: 0~3000mm

(2) Error: ±10mm

(3) Output single: 4-20mA.DC

(4) Load impedance: 550Ω

(5) Power source: 24V.DC;

(6) Outlet: M20*1.5(internal thread)

(7) Ambient temperature:-40~60℃

(8) Anti-explosion grade: dIIBT-4, ibIIBT4

(9) Degrees of protection provided by enclosure: IP65
