D1325A-2 Double Head Multi-Axis CNC Router

Applicable:

Wood, Plastic, Aluminum, Di-Bond, Engraving Board, Foamex. Engineering plastics, marble, acrylic, Perspex, PVC, Composite panel, Copper, Alloys, MDF, etc.

Features:

1.Light grid steel welded structure. high intensity and small vibration

2.High-strength aluminum alloy table.

3.Multi-Axis,high efficiency

4.X.Y axis rack and pinion drive, Z axis precision ball screw drive ensure accurate cuts and speed.

5.24000rpm domestic high-performance spindle.

6.PC-based CNC control system

7.High speed stepper motor

8.Precision rectangular linear guide way, ensure the working accuracy and the long service life.

9.CE Approved

10.Design according to customers requirement.

Specifications

Machine Space-Overall(mm):2930*1800*1500mm

Max working size(mm): 1300*2500*130mm

Frame: Steel Frame

Table Type: T-slot aluminum profile

Spindle: 3kw*2(Option:2.2kw)

Control System: NC6B control software(Option DSP System software)

Guide way: Taiwan Hiwin 20mm rectangle guide rail

Rail way: X.Y axis Rack and pinion, Z axis Precision ball screw

Drive type: Stepper motor(Option: Servo)

Resolution(mm): 0.02mm

Repeatability precision: 0.02mm

Speed:24000rpm

Tool holder diameter:3.175-18mm

Travel speed:14000mm/min

Cutting speed:5000mm/min

Voltage:220v/50Hz

Weight:1200kg

Note: Dimensions and design characteristics shown on this catalog are subject to change without prior notice .
